FC 300 Design Guide
Function:
Defines the Set-up number to control the
functions of the drive.
All parameters are programmed in four individual
parameter Set-ups, Set-up 1 - Set-up 4. Open
loop and closed-loop function can only be
changed with a stop signal applied. The Default
Set-up cannot be modified.
Default Set-up [0] contains the data set at Danfoss.
Can be used as a data source if the other Set-ups are
to be returned to a known state. Par. 0-50 and par.
0-06 allow copying from one Set-up to another or
to all the other Set-ups. Set-ups 1-4 are individual
Set-ups, which can be selected individually.
Multi Set-up [9] is used by remote-selection
between Set-ups. Use digital inputs and the serial
communication port for switching between Set-ups.
Apply a stop signal when switching between Set-ups
where parameters marked as "not changeable
during operation" have different values. To make
sure that parameters marked as "not changeable
during operation" are never set differently in
two Set-ups, you should link the two Set-ups
together via par. 0-12. Parameters that are "not
changeable during operation" are marked FALSE in
the parameter lists in the section Parameter Lists.
0-11 Edit Set-up
Option:
Factory setup
*
Set-up 1
Set-up 2
Set-up 3
Set-up 4
Active Set-up
Function:
Selects Editing Set-up. Editing is done via the
active Set-up or one of the inactive Set-ups.
Selects the Set-up in which to program (change of
data) during operation (applies both via the control
panel and via the serial communication port). You
can program the 4 Set-ups independently of the
active Set-up (selected in par. 0-10).
Factory Set-up [0] contains default data and can be
used as a data source to return the other Set-ups
to a known state. Set-ups 1-4 are individual
Set-ups and can be used as required. They can be
programmed freely, regardless of the active Set-up.
* default setting ( ) display text
How to Program
*
Apply a stop signal when switching between set-ups
where parameters marked as "not changeable
during operation" have different values. To make
sure that parameters marked as "not change
able during operation" are never set differently
in two set-ups, link the two set-ups together.
The adjustable frequency drive will automatically
synchronize the parameter values. Parameters that
are not changeable during operation are marked
FALSE in the section Parameter Lists.
A readout of all the set-ups linked together by
means of par. 0-12. The parameter has one index
for each parameter set-up. Each set-up shows the
set-up bitset linked to that particular set-up.
[0]
[1]
[2]
[3]
[4]
[9]
[ ] value for use in communication via serial communication port
MG.33.B3.22 - VLT is a registered Danfoss trademark
0-12 This Set-up Linked to
Option:
Set-up 1
Set-up 2
Set-up 3
Set-up 4
Function:
0-13 Readout: Linked Set-ups
Array [5]
Range:
0 - 255 N/A
Function:
Example where set-up 1 and 2 are linked:
Index LCP value
0 {0}
1 {1,2}
2 {1,2}
3 {3}
4 {4}
0-14 Readout: Edit Set-ups / Channel
Range:
0 - FFF.FFF.FFF
[1]
[2]
[3]
[4]
*
0 N/A
*
AAA.AAA.AAA
