Danfoss VLT AutomationDrive FC 300 Design Manual page 135

FC 300 Design Guide
Idle Time
Paramdb Requests in Queue
Function:
None [0] No display value chosen
Control Word [1600]
present control word
Reference [Unit] [1601]
of terminals 53 or 54 using the unit stated on the
basis of configuration in P.1-00 (RPM or Nm).
Reference % [1602]
reference (sum of digital/analog/preset/bus/freeze
ref./catch up and slow-down).
Status Word [binary] [1603]
the present status word
Alarm Word [1604]
alarms in a Hex code.
Warning Word [1605]
more warnings in a Hex code.
Extended Status Word [1606]
one or more status states in a Hex code.
Power [kW] [1610]
consumed by the motor in kW.
Power [hp] [1611]
consumed by the motor in HP.
Motor voltage [V] [1612]
supplied to the motor.
Frequency [Hz] [1613]
frequency, i.e. the output frequency from the
adjustable frequency drive.
Motor Current [A] [1614]
current of the motor measured as effective value.
Torque [%] [1616]
in relation to the rated motor torque.
Speed [RPM] [1617]
RPM (revolutions per Minute) i.e. the motor
shaft speed in closed-loop.
Motor Thermal [1618]
timated thermal load on the motor.
DC Link Voltage [V] [1630]
intermediate circuit voltage in the adjustable
frequency drive.
Brake Energy /s [1632]
power transferred to an external brake resistor.
Stated as an instantaneous value.
Brake Energy /2 min [1633]
power transferred to an external brake resistor.
The mean power is calculated continuously
for the latest 120 seconds.
* default setting ( ) display text
How to Program
[9913]
[9914]
Displays the
displays the status value
displays the total
Displays
indicates one or several
indicates one or
[Hex] indicates
states the actual power
states the actual power
states the voltage
gives the motor
states the phase
gives the current motor load
Displays the speed in
states the calculated/es-
states the
states the present brake
states the brake
[ ] value for use in communication via serial communication port
MG.33.B3.22 - VLT is a registered Danfoss trademark
Heatsink Temp. [°C] [1634]
heatsink temperature of the adjustable frequency
drive. The cut-out limit is 203 ± 9°F (95 ± 5°C);
reset occurs at 158 ± 9°F (70 ± 5°C).
Inverter Thermal [1635]
percentage load of the inverters.
Inv. Nom. Current [1636]
of the adjustable frequency drive.
Inv. Max. Current [1637]
of the adjustable frequency drive.
SL Controller State [1638]
of the event executed by the control.
Control Card Temp. [1639]
temperature on control card.
External Reference [1650] [%]
sum of the external reference as a percentage
(the sum of analog/pulse/bus).
Pulse Reference [1651] [Hz]
frequency in Hz connected to the programmed
digital inputs (18, 19 or 32, 33).
Feedback [Unit] [1652]
value from programmed digital input(s).
Digital Input [1660] states the signal states
from the 6 digital terminals (18, 19, 27, 29, 32
and 33) Input 18 corresponds to the bit at the far
left. "0" = signal low; "1" = signal high.
Terminal 53 Switch Setting [1661]
returns the setting of input terminal 53.
Current = 0; Voltage = 1.
Analog Input 53 [1662]
on input 53 either as reference or protection value.
Terminal 54 Switch Setting [1663]
returns the setting of input terminal 54.
Current = 0; Voltage = 1.
Analog Input 54 [1664]
on input 54 either as reference or protection value.
Analog Output 42 [mA] [1665]
actual value in mA on output 42. Selection of
shown value is set in par. 6-50.
Digital Output [bin] [1666]
value of all digital outputs.
Freq. Input #29 [Hz] [1667]
the actual value of the frequency applied on
terminal 29 as an impulse input.
Freq. Input #33 [Hz] [1668]
the actual value of the frequency applied on
terminal 33 as an impulse input.
Pulse output #27 [Hz] [1669]
actual value of impulses applied to terminal
27 in digital output mode.
states the present
returns the
The nominal current
The maximum current
returns the state
returns the
gives the
states the
returns the reference
returns the actual value
returns the actual value
returns the
returns the bin
returns
returns
returns the
135
