FC 300 Design Guide
Thermal warning [16] - see par. 5-31
for further description.
Mains voltage out of range [17] - see par.
5-31 for further description.
Reversing [18] - see par. 5-31 for
further description.
Warning [19] - see par. 5-31 for further
description.
Alarm (trip) [20] - see par. 5-31 for
further description.
Alarm (trip lock) [21] - see par. 5-31
for further description.
Comparator 0 [22] - use the result of
comparator 0 in the event.
Comparator 1 [23] - use the result of
comparator 1 in the event.
Comparator 2 [24] - use the result of
comparator 2 in the event.
Comparator 3 [25] - use the result of
comparator 3 in the event.
Logic rule 0 [26] - use the result of logic
rule 0 in the event.
Logic rule 1 [27] - use the result of logic
rule 1 in the event.
Logic rule 2 [28] - use the result of logic
rule 2 in the event.
Logic rule 3 [29] - use the result of logic
rule 3 in the event.
Time-out 0 [30] - use the result of
timer 0 in the event.
Time-out 1 [31] - use the result of
timer 1 in the event.
Time-out 2 [32] - use the result of
timer 2 in the event.
Digital input DI18 [33] - use the value of
DI18 in the event (High = TRUE).
Digital input DI19 [34] - use the value of
DI19 in the event (High = TRUE)
Digital input DI27 [35] - use the value of
DI27 in the event (High = TRUE).
Digital input DI29 [36] - use the value of
DI29 in the event (High = TRUE).
Digital input DI32 [37] - use the value of
DI32 in the event (High = TRUE).
Digital input DI33 [38] - use the value of
DI33 in the event (High = TRUE).
13-52 SL Controller Action
Array [6]
*
default setting
( )
display text
How to Program
*
Actions are executed when the corresponding event
(defined in par. 13-51) is evaluated as true. The
following list of actions is available for selection.
[ ]
value for use in communication via serial communication port
MG.33.B3.22 - VLT is a registered Danfoss trademark
Option:
Disabled
No action
Select set-up 0
Select set-up 1
Select set-up 2
Select set-up 3
Select preset reference 0
Select preset reference 1
Select preset reference 2
Select preset reference 3
Select preset reference 4
Select preset reference 5
Select preset reference 6
Select preset reference 7
Select ramp 1
Select ramp 2
Select ramp 3
Select ramp 4
Run
Run reverse
Stop
Qstop
Dcstop
Coast
Freeze output
Start timer 0
Start timer 1
Start timer 2
Set digital output A low
Set digital output B low
Set digital output C low
Set digital output D low
Set digital output E low
Set digital output F low
Set digital output A high
Set digital output B high
Set digital output C high
Set digital output D high
Set digital output E high
Set digital output F high
Function:
*DISABLED [0]
No action [1]
[0]
[1]
[2]
[3]
[4]
[5]
[10]
[11]
[12]
[13]
[14]
[15]
[16]
[17]
[18]
[19]
[20]
[21]
[22]
[23]
[24]
[25]
[26]
[27]
[28]
[29]
[30]
[31]
[32]
[33]
[34]
[35]
[36]
[37]
[38]
[39]
[40]
[41]
[42]
[43]
