FC 300 Design Guide
On reference [4] - see par. 5-31 for
further description.
Torque limit [5] - see par. 5-31 for
further description.
Current limit [6] - see par. 5-31 for
further description.
Out of current range [7] - see par. 5-31
for further description.
Below I low [8] - see par. 5-31 for
further description.
Above I high [9] - see par. 5-31 for
further description.
Below frequency low [11] - see par. 5-31
for further description.
Above frequency high [12] - see par. 5-31
for further description.
Thermal warning [16] - see par. 5-31
for further description.
Mains voltage out of range [17] - see par.
5-31 for further description.
Reversing [18] - see par. 5-31 for
further description.
Warning [19] - see par. 5-31 for further
description.
Alarm (trip) [20] - see par. 5-31 for
further description.
Alarm (trip lock) [21] - see par. 5-31
for further description.
Comparator 0 [22] - use the result of
comparator 0 in the logic rule.
Comparator 1 [23] - use the result of
comparator 1 in the logic rule.
Comparator 2 [24] - use the result of
comparator 2 in the logic rule.
Comparator 3 [25] - use the result of
comparator 3 in the logic rule.
Logic rule 0 [26] - use the result of logic
rule 0 in the logic rule.
Logic rule 1 [27] - use the result of logic
rule 1 in the logic rule.
Logic rule 2 [28] - use the result of logic
rule 2 in the logic rule.
Logic rule 3 [29] - use the result of logic
rule 3 in the logic rule.
Time-out 0 [30] - use the result of timer
0 in the logic rule.
Time-out 1 [31] - use the result of timer
1 in the logic rule.
Time-out 2 [32] - use the result of timer
2 in the logic rule.
default setting
( )
display text
*
200
How to Program
*
Selects the logical operator to use on the Boolean
inputs from par. 13-40 and 13-42.
[13 -XX] signifies the Boolean input of par. 13-*.
[ ]
value for use in communication via serial communication port
MG.33.B3.22 - VLT is a registered Danfoss trademark
Digital input DI18 [33] - use the value of DI18
in the logic rule (High = TRUE).
Digital input DI19 [34] - use the value of DI19
in the logic rule (High = TRUE).
Digital input DI27 [35] - use the value of DI27
in the logic rule (High = TRUE).
Digital input DI29 [36] - use the value of DI29
in the logic rule (High = TRUE).
Digital input DI32 [37] - use the value of DI32
in the logic rule (High = TRUE).
Digital input DI33 [38] - use the value of DI33
in the logic rule (High = TRUE).
13-41 Logic Rule Operator 1
Array [4]
Option:
Disabled
And
Or
And not
Or not
Not and
Not or
Not and not
Not or not
Function:
DISABLED [0] - select this option to ignore
par. 13-42, 13-43, and 13-44.
AND [1] - evaluates the expression
[13-40] AND [13-42].
OR [2] - evaluates the expression
[13-40] OR [13-42].
AND NOT [3] - evaluates the expression
[13-40] AND NOT [13-42].
OR NOT [4] - evaluates the expression
[13-40] OR NOT [13-42].
NOT AND [5] - evaluates the expression
NOT [13-40] AND [13-42].
NOT OR [6] - evaluates the expression
NOT [13-40] OR [13-42].
NOT AND NOT [7] - evaluates the expression
NOT [13-40] AND NOT [13-42].
NOT OR NOT [8] - evaluates the expression
NOT [13-40] OR NOT [13-42].
[0]
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
