FC 300 Design Guide
Ready, voltage OK
Reverse
Bus OK
Torque limit stop
Brake, no warning
Brake ready, no fault
Brake fault (IGBT)
Relay 123
Mech. brake control
Safe stop active
MCO controlled
Comparator 0
Comparator 1
Comparator 2
Comparator 3
Logic rule 0
Logic rule 1
Logic rule 2
Logic rule 3
SL digital output A
SL digital output B
SL digital output C
SL digital output D
SL digital output E
SL digital output F
Local ref. active
Remote ref. active
No alarm
Start cmd. active
Running reverse
Drive in hand mode
Drive in auto mode
You can program the digital outputs to
these functions:
No operation [0]: Default for all digital
•
outputs and relay outputs
Control ready [1]: The control board
•
receives supply voltage.
Drive ready [2]: The adjustable frequency
•
drive is ready for operation and applies a
supply signal on the control board.
Drive ready / remote
•
frequency drive is ready for operation
and is in Auto On mode.
Enable / no warning
•
frequency drive is ready for use. No start or
stop command has been given (start/disable).
There are no warnings.
• VLT running [5]: The motor is running.
Running / no warning
•
is higher than the speed set in par. 1-81. The
motor is running and there are no warnings.
* default setting ( ) display text
How to Program
[24]
[25]
[26]
[27]
[28]
[29]
[30]
[31]
[32]
[33]
[51]
[60]
[61]
[62]
[63]
[70]
[71]
[72]
[73]
[80]
[81]
[82]
[83]
[84]
[85]
[120]
[121]
[122]
[123]
[124]
[125]
[126]
[3]: The adjustable
[4]: The adjustable
[6]: The output speed
[ ] value for use in communication via serial communication port
MG.33.B3.22 - VLT is a registered Danfoss trademark
Run in rnge, no warn
•
the programmed current/speed ranges set
in par. 4-50 to par. 4-53.
Run on ref., no warn.
•
speed according to reference.
Alarm [9]: An alarm activates the output.
•
Alarm or warning
•
warning activates the output.
At torque limit [11]: The torque limit set in
•
par. 4-16 or par. 1-17 is exceeded.
Out of current range
•
is outside the range set in par. 4-18.
• Below current, low
is lower than set in par. 4-50.
Above current, high
•
is higher than set in par. 4-51.
Out of speed range [15]
•
Below speed, low[16]: The output speed
•
is lower than set in par. 4-52.
Above speed, high
•
is higher than set in par. 4-53.
Thermal warning [21]: Thermal warning
•
is on when the temperature is above limit in
the motor, the adjustable frequency drive, the
brake resistor, or the thermistor.
Ready, no thrm warn
•
frequency drive is ready for operation and
there is no overtemperature warning.
Rmte rdy, no th wrn
•
frequency drive is ready for operation
and is in Auto On mode. There is no
overtemperature warning.
Ready, voltage OK
•
frequency drive is ready for operation and the
line voltage is within the specified voltage range
(see section General Specifications).
Reverse [25]: Reversing. Logic '1' = relay
•
activated, 24 V DC when CW rotation of the
motor. Logic '0' = relay not activated, no signal,
when CCW rotation of the motor.
• Bus OK [26]: Active communication (no
timeout) via the serial communication port.
Torque limit stop [27]: Is used when
•
performing a coasting stop and in torque
limit condition. If the adjustable frequency
drive has received a stop signal and is at the
torque limit, the signal is Logic '0'.
Brake, no warning
•
active and there are no warnings.
[7]: Runs within
[8]: Mechanical
[10]: An alarm or a
[12]: The motor current
[13]: The motor current
[14]: The motor current
[17]: The output speed
[22]: The adjustable
[23]: The adjustable
[24]: The adjustable
[28]: The brake is
