Parameter Descriptions
4.19.3 22-6* Broken-belt Detection
Use broken-belt detection in both closed-loop systems and
open-loop systems for pumps and fans. If the estimated
motor torque (current) is below the broken-belt torque
(current) value (parameter 22-61 Broken Belt Torque), the
frequency converter output frequency is above or equal to
15 Hz, and the condition has been active for
parameter 22-62 Broken Belt Delay, parameter 22-60 Broken
Belt Function is performed.
22-60 Broken Belt Function
Option: Function:
Select the actions to be performed
if the broken-belt condition is
detected.
[0] Off
*
[1] Warning The frequency converter continues
to run, but activates warning 95,
Broken belt. A frequency converter
digital output or a serial communi-
cation bus communicates a warning
to other equipment.
[2] Trip The frequency converter stops
running and activates alarm 95,
Broken belt. A frequency converter
digital output or a serial communi-
cation bus communicates an alarm
to other equipment.
[3] Stop and Trip
22-61 Broken Belt Torque
Range: Function:
10 % [0 - 100 %] Set the broken-belt torque as a
*
percentage of the rated motor
torque.
22-62 Broken Belt Delay
Range: Function:
10 s [0 - 600 s] Set the time for which the broken-
*
belt conditions must be active
before carrying out the action
selected in parameter 22-60 Broken
Belt Function.

4.20 Parameters: 30-** Special Features

4.20.1 30-2* Adv. Start Adjust
30-20 High Starting Torque Time [s]
Range: Function:
Size [0 - 60 s] This function is active together with
related speed control closed loop. In order
*
to obtain a high starting torque,
approximately 2 x I
MG06J202
Programming Guide
30-20 High Starting Torque Time [s]
Range:
30-21 High Starting Torque Current [%]
Range:
Size
related
*
30-22 Locked Rotor Protection
Option:
[0]
[1]
30-23 Locked Rotor Detection Time [s]
Range:
Size
related
*
30-24 Locked Rotor Detection Speed Error [%]
Range:
25 %
*

4.21 Parameters: 40-** Special Settings

40-40 Fault Log: Ext. Reference
Range:
0 %
*
40-41 Fault Log: Frequency
Range:
0 Hz
*
40-42 Fault Log: Current
Range:
0 A
*
for
VLT,N
Danfoss A/S © 03/2019 All rights reserved.
Function:
maximum 0.5 s. However, the
current is limited by the protection
limit of the frequency converter.
Function:
[ 0 - 200.0 %] High starting torque current for PM
motor in VVC + mode without
feedback.
Function:
Available for PM motors only, in
+
VVC open-loop mode.
Off
On Protects the motor from the locked
rotor condition. The control
algorithm detects a possible locked
rotor condition in the motor and
trips the frequency converter to
protect the motor.
Function:
[0.05 - 1 s] Time period for detecting the
locked rotor condition. A low
parameter value leads to faster
detection.
Function:
[0 - 100 %]
Function:
[-200 - View the present reference value
200 %] applied on impulse or analog basis,
when the logged event occurred.
Function:
[0 - 6500 Hz] View the actual motor frequency
value, when the logged event
occurred.
Function:
[0 - 10000 A] View the motor current measured
when the logged event occurred.
4 4
