Parameter Descriptions

4.16 Parameters: 17-** Feedback Options

4.16.1 17-1* Inc.Enc.Interface

17-10 Signal Type
Option:
[0] None
[1] RS422 (5V TTL)
*
[2] Sinusoidal 1Vpp
17-11 Resolution (PPR)
Range:
1024 [10 - 10000 ]
*

4.16.2 17-5* Resolver Interface

17-50 Poles
Range:
2 [2 - 2 ]
*
17-51 Input Voltage
Range:
7 V [2 - 8 V]
*
17-52 Input Frequency
Range:
10 kHz [2 - 15 kHz]
*
17-53 Transformation Ratio
Range:
0.5 [0.1 - 1.1 ]
*
17-56 Encoder Sim. Resolution
Option:
[0] Disabled
*
[1] 512
[2] 1024
[3] 2048
[4] 4096
17-59 Resolver Interface
Option:
[0] Disabled
*
[1] Enabled
MG06C402
Programming Guide
Function:
Function:
Function:
Function:
Function:
Function:
Function:
Function:
Danfoss A/S © Rev. 2014-03-31 All rights reserved.

4.16.3 17-6* Monitoring and App.

17-60 Feedback Direction
Option:
[0] Clockwise
*
[1] Counter clockwise
17-61 Feedback Signal Monitoring
Option:
[0] Disabled
[1] Warning
*
[2] Trip
[3] Jog
[4] Freeze Output
[5] Max Speed
[6] Switch to Open Loop
Function:
4
Function:
101
4
