7.9.5 UPS Output

Path:
MEASUREMENT
After entering the UPS OUTPUT screen (shown in the figure below), you can view the
readings of Phase Voltage, Line Voltage, Current, Frequency, Load, Apparent Power,
Active Power and Power Factor.
UPS-1.1
UPS OUTPUT
Phase Voltage (V)
Line Voltage (V)
Current (A)
Frequency (Hz)
Load (%)

7.9.6 Battery Status

Path:
MEASUREMENT
After entering the BATTERY STATUS
readings of Status, Voltage, Current, Remaining Capacity, Remaining Time, Estimated
Recharging Time, Test Result, Battery Temperature (#1 ~ #4), and each power module's
Charge Voltage and Charge Current.
UPS-1.1
BATTERY STATUS
Status
Voltage (V)
Current (A)
Remaining Capacity (%)
Remaining Time (mins)
Estimated Recharging Time (mins)
MEASUREMENT SETUP MAINTENANCE
UPS Output
220.0 220.0 220.0
380.0 380.0 380.0
300.0 300.0 300.0
50.0
30% 30% 30%
MEASUREMENT SETUP MAINTENANCE
Battery Status
None
+ 272.0
- 272.0
05:00
00:00
LOG IN EVENT LOG
Administrator
Apparent Power (kVA)
Active Power (kW)
Power Factor
LOG IN EVENT LOG
Administrator
PAGE PAGE
1 2
Test Result
Battery Temp. #1 (°C)
Battery Temp. #2 (°C)
+ 0
- 0
Battery Temp. #3 (°C)
90
Battery Temp. #4 (°C)
7-25
