SV-DA200 series AC servo drives

1.3 Cables

1.3.1 Nameplate of cables
5m power flexible towline cable ， 0.75mm cable
diameter ， 4PIN plastic piug ， 7PIN 20A plug
1.3.2 Naming of the power cables
Symbol
①
②
Cable diameter
③
④
Plug on motor end
⑤
R
上海英威腾工业技术有限公司
INVT INDUSTRIAL TECHNOLOGY(SHANGHAI)CO.,LTD.
DAML-075-05-ABF-00
Instruction
Product series For internal use by manufacturer
Power cable ML: Power cable
075: 0.75mm
100: 1.0mm
150: 1.5mm
250: 2.5mm
400: 4.0mm
600: 6.0mm
10R: 10mm
16R: 16mm
25R: 25mm
03: 3m
05: 5m
Cable length
10: 10m
......
A: 4PIN plastic plug
B: 4PIN regular aviation plug YD28
67002-00351
Naming instance
2
2
2
2
2
2
2
2
2
‐7‐
Product overview
