SV-DA200 series AC servo drives
2.3.4 Outline and installation dimension for 110 bases (mm)
Motor model (2500-PPR/multi-turn
absolute value/rotary transformer)
SV-MM11-0R8E-2-□A□
SV-MM11-1R2G-2-□A□
SV-MM11-1R5G-2-□A□
SV-MM11-1R2E-2-□A□
SV-MM11-1R8G-2-□A□
Permanent magnet
W/o brake
brake
189
204
219
‐18‐
Installation instruction
L(mm)
Electromagnetic
brake
245
260
275
263
278
293
