This parameter is used to set the regenerative brake mode and overload protection mode.
Setting value
[0]
1
2
Data size
1
P4.34
Modbus address
Undervoltage protection of
1
P4.36
main power supply
This parameter is used to set whether the drive will report main circuit undervoltage alarm when
undervoltage occurs to the main power supply.
Setting value
0 Do not display the undervoltage fault of the main circuit (Er13-1)
[1] Display the undervoltage fault of the main circuit (Er13-1) and stop
Data size
1
P4.36
Modbus address
Undervoltage detection time
P4.37
of main power supply
This parameter is used to set the undervoltage detection time of the main power supply.
Note: The function is invalid if it is set to 2000.
Data size
P4.37
Modbus address
P4.39 Speed deviation setting
This parameter is used to set the detection condition of the speed error. If the absolute value of
the minus of actual speed command and motor speed is larger than this value and lasts for more
than 100ms, it will report speed error alarm.
Note: If it is set to 0, the speed error will not be detected.
Data size
P4.39
Modbus address
P4.40 Forward speed limit
This parameter is used to set the max. speed limit for forward speed command.
Note: The default value and setting range of the parameter is relative to the drive power level.
Data size
P4.40
Modbus address
Regenerative brake and overload protection
Disabled (no regenerative brake)
Embedded
External
16bit
1868,1869
Setting range
0~1
16bit
1872,1873
Setting range
70~2000
16bit
1874,1875
Setting range
0~20000
16bit
1878,1879
Setting range
0~20000
16bit
1880,1881
‐142‐
Data format
CANopen address
Default Unit
1
Protection
Data format
CANopen address
Default Unit
70 ms
Data format
CANopen address
Default Unit
0 r/min
Data format
CANopen address
Default Unit
20000 r/min
Data format
CANopen address
Faults and solutions
DEC
0x2422,0x00
Available mode
- P S T
DEC
0x2424,0x00
Available mode
P S T
DEC
0x2425,0x00
Available mode
P S
DEC
0x2427,0x00
Available mode
P S T
DEC
0x2428,0x00
F
F
F
