1.3.6 Naming of motor braking cables
Symbol
①
②
Plug on motor end
③

1.4 Braking resistor specification

Drive model
SV-DA200-0R1-2
SV-DA200-0R2-2
SV-DA200-0R4-2
SV-DA200-0R7-2
SV-DA200-1R0-2
SV-DA200-1R5-2
SV-DA200-2R0-2
SV-DA200-3R0-2
SV-DA200-4R4-2
SV-DA200-1R0-4
SV-DA200-1R5-4
SV-DA200-2R0-4
SV-DA200-3R0-4
SV-DA200-4R4-4
SV-DA200-5R5-4
SV-DA200-7R5-4
SV-DA200-011-4
SV-DA200-015-4
SV-DA200-022-4
Instruction
Product series
Cable length
Embedded braking
Naming instance
BRKL: motor brake cable
03: 3m
05: 5m
10: 10m
30: 30m
A: 2PIN metal plug
B: 3PIN regular aviation plug
C: 3PIN metal plug
resistor
/
/
/
30Ω 60W
30Ω 60W
30Ω 60W
15Ω 120W
15Ω 120W
15Ω 120W
60Ω 60W
60Ω 60W
60Ω 60W
60Ω 60W
30Ω 120W
30Ω 120W
/
/
/
/
‐10‐
Product overview
Min. resistance of external
braking resistors
60Ω
60Ω
60Ω
30Ω
30Ω
20Ω
15Ω
15Ω
15Ω
60Ω
60Ω
40Ω
30Ω
30Ω
30Ω
30Ω
20Ω
15Ω
10Ω
