SV-DA200 series AC servo drives
3.1.4 EMI filter
Drive model
SV-DA200-0R1-2
SV-DA200-0R2-2
SV-DA200-0R4-2
SV-DA200-0R7-2
SV-DA200-1R0-4
SV-DA200-1R5-4
SV-DA200-1R0-2
SV-DA200-1R5-2
SV-DA200-2R0-4
SV-DA200-3R0-4
SV-DA200-2R0-2
SV-DA200-3R0-2
SV-DA200-4R4-4
SV-DA200-4R4-4
SV-DA200-5R5-4
SV-DA200-7R5-4
SV-DA200-011-4
SV-DA200-015-4
SV-DA200-022-4
Note: The EMI filter models in the table are the models of our company and they are used for power
input terminal.
EMI filter model
FLT-P04006L-B
FLT-P04016L-B
FLT-P04032L-B
FLT-P04045L-B
FLT-P04065L-B
FLT-P04100L-B
‐27‐
Wiring instruction
