SV-DA200 series AC servo drives
2.3.3 Outline and installation dimension for 80 bases (mm)
Motor model (2500-PPR/multi-turn
absolute value/rotary transformer)
SV-ML08-0R7G-2-□A□
SV-MH08-0R7G-2-□A□
Motor model
(17-bit single-turn encoder)
SV-ML08-0R7G-2-3A□
Permanent magnet
W/o brake
brake
140
151
W/o brake
141
‐17‐
Installation instruction
L(mm)
Electromagnetic
brake
186
205
L(mm)
Electromagnetic brake
173
186
205
