INVT SV-DA200 Operation Manual page 30

SV-DA200 series AC servo drives
2.3.6 Outline and installation dimension for 180 bases (mm)
Motor model (2500-PPR/multi-turn
absolute value/rotary transformer)
SV-MM18-3R0B-□-□A□
SV-MM18-4R4B-□-□A□
SV-MM18-5R5B-4-□A□
SV-MM18-7R5B-4-□A□
SV-SM18-7R5B shaft extension dimension (mm):
Motor model (2500-PPR/multi-turn
absolute value/rotary transformer)
SV-SM18-7R5B-4-□A□
Permanent magnet
W/o brake
232
262
292
346
Permanent magnet
W/o brake
375
‐20‐
Installation instruction
∅ 200
∅13.5
L(mm)
Electromagnetic
brake
314
344
382
436
L(mm)
Electromagnetic
brake
465
brake
304
334
364
418
brake
455
