SV-DA200 series AC servo drives
Display
Er02-8 Encoder fault–Low voltage alarm of the encoder
Er02-9 Encoder fault–Undervoltage alarm of the encoder
Er02-a Encoder fault–Encoder over-temperature
Er02-b Encoder fault–EEPROM write error
Er02-c Encoder fault–EEPROM no data
Er02-d Encoder fault–EEPROM data check error
Er03-0 Current sensor fault–U phase IGBT fault
Er03-1 Current sensor fault–V phase IGBT fault
Er03-2 Current sensor fault–W phase IGBT fault
Er04-0 System initialization fault
Er05-1 Setting fault–Motor model error
Er05-2 Setting fault–Motor and drive model error
Er05-3 Setting fault–Software limit setting error
Er05-4 Setting fault–Homing mode setting fault
Er05-5 Setting fault–Position control overflow fault
Er07-0 Regeneration discharge overload fault
Er08-0 Analog input overvoltage fault–Analog input 2
Er08-1 Analog input overvoltage fault–Analog input 3
Er08-2 Analog input overvoltage fault–Analog input 3
Er09-0 EEPROM fault–Read-write fault
Er09-1 EEPROM fault–data check fault
Er10-0 Hardware fault–FPGA fault
Er10-1 Hardware fault–Communication card fault
Er10-2 Hardware fault–Grounding short circuit fault
Er10-3 Hardware fault–External input fault
Er10-4 Hardware fault–Emergency stop fault
Er10-5 Hardware fault–485 communication fault
Er11-0 Software fault-Motor control task re-entry
Er11-1 Software fault–Reentrant cycle mission
Er11-2 Software fault–Illegal operation
Er12-0 IO fault–Repeat digital input distribution
Er12-1 IO fault-Repetitive analog input distribution
Er12-2 IO fault–Pulse input frequency is too high
Er13-0 Main circuit overvoltage fault
Er13-1 Main circuit undervoltage fault
Er14-0 Undervoltage control power fault
Er17-0 Drive overload fault
Fault name
‐226‐
32-bit fault code(16-bit Error
Code+16-bit additional message)
7300-0208h
7300-0209h
7300-020Ah
7300-020Bh
7300-020Ch
7300-020Dh
7300-0300h
7300-0301h
7300-0302h
FF01-0400h
FF01-0501h
FF01-0502h
FF01-0503h
FF01-0504h
FF01-0505h
7100-0700h
5441-0800h
5442-0801h
5443-0802h
5530-0900h
5530-0901h
5544-0A00h
5544-0A01h
5544-0A02h
5544-0A03h
4458-0A04h
4458-0A05h
6100-0B00h
6100-0B01h
6100-0B02h
FF01-0C00h
FF01-0C01h
FF01-0C02h
3110-0D00h
3120-0D01h
5200-0E00h
FF01-1100h
Communication
