LPOD C-, X-, or Ku-Band Outdoor Amplifier / Block Up Converter (BUC)
Appendix A
ITEM QTY CEFD PART NO.
1 1 28P1084
2 1 CN/CX50NMALE
3 1 SW/WGS28V-229SM
4 4 GA/GSKTCPR229FULL
5 12 03P1078
6 32 HW/1/4-20X5/8HEX
7 42 HW/1/4-FLT
8 42 HW/1/4-SPLIT

Table A-2. Parts List for KT-0000098 LPOD C-Band Rx Switch Kit

KT-0000098 LPOD C-BAND RX SWITCH KIT (AS PER FIGURE A-6)
DESCRIPTION
QP RF ADAPTER, N (FEM) TO CPRG229 W/G GROOVED FOR 1/2 GASKET
CONNECTOR, CN-50-OHM,N, MALE TERMINATION
SWITCH, WAVEGUIDE, CPR229 GROOVED, +28V SEALED (MS3116F10-6S MATING CONN)
GASKET, CPR229, FULL THK
1/4-20 x 3/4 LG HEX BOLT, SS
1/4-20 x 5/8 LG HEX HD SCREW, SS
1/4" FLAT WASHER
1/4" SPLIT WASHER
A–16
MN-LPOD
Revision 14
