Optional Internal Reference; Optional Lnb Bias / Reference; Environmental - Comtech EF Data LPOD PS 1.5 Installation And Operation Manual

LPOD C-, X-, or Ku-Band Outdoor Amplifier / Block Up Converter (BUC)
Introduction
Phase Noise (dBc/Hz) (with optional
internal or equivalent performance
external reference)
Offset

1.5.2 Optional Internal Reference

Internal Reference Oscillator Frequency
Frequency Stability

1.5.3 Optional LNB Bias / Reference

LNB Bias Voltage
LNB 10 MHz Reference Output Level
LNB Input / Output Return Loss
LNB Input / Output Gain
LNB Input / Output Gain Flatness
LNB input / Output Isolation (Mute
condition)

1.5.4 Environmental

Operating
Temperature
Storage
Humidity
Altitude
Shock
Typical (C/X/Ku) dBc/Hz
100 Hz -79/-78/-76
1 KHz -91/-87/-85
10 KHz -105/-104/-98
100 KHz -120/-114/-114
1 MHz -132/-132/-132
10 MHz (can lock to modem supplied reference over
a range of -5 dBm to +5 dBm at IF Input)
–10
±5 x 10
-8
±1 x 10
Software selectable tone on/off, 12/18V, 450 mA
max
0 dBm ±5 dB
15 dB
10 dB ± 2 dB (950-1750 MHz)
-1 dB ± 2 dB (optional)
± 1 dB (950-1750 MHz)
55 dB min
Standard -40° to 131°F (-40° to 55°C)
Optional -40° to 140°F (-40° to 60°C)
-67° to 167°F (-55° to 75°C)
100% condensing rain 2" per hour
10,000 AMSL
Normal commercial shipping and handling
1–12
Spec (C/X/Ku) dBc/Hz
-72/-72/-69
-84/-84/-82
-97/-97/-90
-107/-107/-102
-115/-115/-115
/day
(-40° to 55°C)
MN-LPOD
Revision 14
