STC Control Registers

10.8.4 STC Current ROM Address Register - CORE1 (STCCADDR1)

This register is described in
NOTE: When the RS_CNT bit in STCGCR0 is set to a 1 on the start of a self-test run, or on a
power-on reset or system reset, this register resets to all zeroes.
Figure 10-11. STC Current ROM Address Register (STCCADDR1) [offset = 0Ch]
31
LEGEND: R = Read only; -n = value after nPORST (power on reset) or System reset
Table 10-12. STC Current ROM Address Register (STCCADDR1) Field Descriptions
Bit Field Description
31-0 ADDR Current ROM Address
This register reflects the current ROM address (address or micro code load) accessed during self-test
Segment0 -Core1 and other segments. This is the current value of the STC program counter.

10.8.5 STC Current Interval Count Register (STCCICR)

This register is described in
NOTE: When the RS_CNT bit in STCGCR0 is set to a 1 or on a power-on reset, the current interval
counter resets to the default value.
Figure 10-12. STC Current Interval Count Register (STCCICR) [offset = 10h]
31
15
LEGEND: R = Read only; -n = value after reset
Table 10-13. STC Current Interval Count Register (STCCICR) Field Descriptions
Bit Field
31-16 CORE2_ICOUNT
15-0 CORE1_ICOUNT
450
Self-Test Controller (STC) Module
Figure 10-11 and
Figure 10-12 and
CORE2_ICOUNT
CORE1_ICOUNT
Description
Interval Number
This specifies the last executed interval number for Core2 in case of self-test being run on Segement0
redundant cores.
Interval Number
This specifies the last executed interval number for Core1 in case of self-test being run on Segment0 or
any other segments.
