7.11.4 POM Region Start Address Register (POMPROGSTARTx)

This set of registers contains the start address of each region which is to be remapped. These registers
are at an offset 200h + (10h x region number). Region numbers are counted from 0 onwards.
Figure 7-49. POM Region Start Address Register (POMPROGSTARTx) (offset = 200h, 210h,..)
31
15
LEGEND: R/W = Read/Write; R = Read only; WP = Write in Privilege Mode; -n = value after reset
Table 7-52. POM Region Start Address Register (POMPROGSTARTx)
Bit Field
31-23 Reserved
22-6 STARTADDRESS
5-0 Reserved

7.11.5 POM Overlay Region Start Address Register (POMOVLSTARTx)

Contains the start address of the overlay region in volatile memory.
Figure 7-50. POM Overlay Region Start Address Register (POMOVLSTARTx) (offset = 204h, 214h,...)
31
15
LEGEND: R/W = Read/Write; R = Read only; WP = Write in Privilege Mode; -n = value after reset
Table 7-53. POM Overlay Region Start Address Register (POMOVLSTARTx)
Bit Field
31-23 Reserved
22-6 STARTADDRESS
5-0 Reserved
SPNU563A – March 2018
Submit Documentation Feedback
Reserved
R-0
STARTADDRESS
R/WP-0
Field Descriptions
Value Description
0 Reads return 0. Writes have no effect.
Start address of the program memory region.
0 Reads return 0. Writes have no effect.
Reserved
R-0
STARTADDRESS
R/WP-0
Field Descriptions
Value Description
0 Reads return 0. Writes have no effect.
Start address of the program memory region.
0 Reads return 0. Writes have no effect.
Copyright © 2018, Texas Instruments Incorporated
23 22
STARTADDRESS
6 5
23 22
STARTADDRESS
6 5
F021 Level 2 Flash Module Controller (L2FMC)
POM Control Registers
16
R/WP-0
0
Reserved
R-0
16
R/WP-0
0
Reserved
R-0
