Table 22-60. ADC Magnitude Compare Interrupt Control Registers (ADMAGINTxCR)
Field Value
Reserved 0
MAG_CHIDx
MAG_THRx
COMP_CHIDx
CHN_THR_COMPx
0
1
CMP_GE_LTx
0
1
SPNU563A – March 2018
Submit Documentation Feedback
Field Descriptions
Description
Reads return 0. Writes have no effect.
These bits specify the channel number from 0 to 31 for which the conversion result needs to be
monitored by the ADC.
These bits specify the 12-bit or 10-bit compare value that the ADC will use for the comparison with the
MAG_CHIDx channel's conversion result.
These bits specify the channel number from 0 to 31 whose last conversion result is compared with the
MAG_CHIDx channel's conversion result.
Channel OR Threshold comparison.
Any operation mode read/write:
The ADC module will compare the MAG_CHIDx channel's conversion result with the fixed threshold
value specified by the MAG_THRx field
The ADC module will compare the MAG_CHIDx channel's conversion result with the last conversion
result for the COMP_CHIDx channel.
Both the MAG_CHIDx and the COMP_CHIDx channel must have been converted at least once for the
ADC to perform the comparison.
"Greater than or equal to" OR "Less than" comparison operator.
Any operation mode read/write:
The ADC module will check if the conversion result is lower than the reference value (fixed threshold
or COMP_CHIDx conversion result).
The ADC module will check if the conversion result is greater than or equal to the reference value
(fixed threshold or COMP_CHIDx conversion result).
