behavior by the interconnect. For example, if the CPU issues a burst read request to the flash, the
checker will ensure that the expected behavior is indeed a burst read request to the proper slave module.
If the interconnect generates a transaction which is not a read, or not a burst or not to the flash as the
destination, then the checker will flag it in one of the registers. The detected error will also be signaled to
the ESM module. Table 4-2

2.1.5 Interconnect Subsystem Runtime Status

Other than the runtime checker status as described in
and the Peripheral Interconnect Subsystem in the microcontroller also generates several status onto the
system that are captured in the SCM (SCR Control Module).

2.1.6 Master ID to PCRx

The master ID associated with each master port on the Peripheral Interconnect Subsystem contains a 4-
bit value. The master ID is passed along with the address and control signals to three PCR modules. PCR
decodes the address and control signals to select the peripheral. In addition, it decodes this 4-bit master
ID value to perform memory protection. With 4-bit of master ID, it allows the PCR to distinguish among 16
different masters to allow or dis-allow access to a given peripheral. Associated with each peripheral a 16-
bit Master ID access protection register is defined. Each bit grants or denies the permission of the
corresponding binary coded decimal masterID. For example, if bit 5 of the access permission register is
set, it grants master ID 5 to access the peripheral. If bit 7 is clear, it denies master ID 7 to access the
peripheral. Figure 2-2
capable of accessing the PCRx is listed in
definition.
SPNU563A – March 2018
Submit Documentation Feedback
lists the CPU Interconnect Subsystem SDC register bit field mapping.
illustrates the Master-ID filtering scheme. The master ID of each master that is
Table
Figure 2-2. PCR MasterID Filtering
MasterID
4
ID Decode
0
1
2
13
14
15
Copyright © 2018, Texas Instruments Incorporated
Section 2.1.4, the CPU Interconnect Subsystems
Table 4-4 lists the SCM register bit mapping.
4-1. Also see Section 2.5.3
Address/Control
Addr Decode
Peripheral Select N
PCRx
Introduction
for details on the registers
Architecture
