20.3.1.9 Channel Priority Set Register (CHPRIOS)
Figure 20-27. Channel Priority Set Register (CHPRIOS) [offset = 34h]
31
LEGEND: R/W = Read/Write; WP = Write in privilege mode only; -n = value after reset
Table 20-17. Channel Priority Set Register (CHPRIOS) Field Descriptions
Bit Field Value
31-0 CPS[n]
0
1
20.3.1.10 Channel Priority Reset Register (CHPRIOR)
Figure 20-28. Channel Priority Reset Register (CHPRIOR) [offset = 3Ch]
31
LEGEND: R/W = Read/Write; WP = Write in privilege mode only; -n = value after reset
Table 20-18. Channel Priority Reset Register (CHPRIOR) Field Descriptions
Bit Field Value
31-0 CPR[n]
0
1
SPNU563A – March 2018
Submit Documentation Feedback
CPS[31:0]
R/WP-0
Description
Channel priority set bit. Bit 0 corresponds to channel 0, bit 1 corresponds to channel 1, and so on.
Writing a 1 to a bit assigns the corresponding channel to the high priority queue.
Read: The corresponding channel is assigned to the low priority queue.
Write: No effect.
Read and write: The corresponding channel is assigned to high priority queue.
CPR[31:0]
R/WP-0
Description
Channel priority reset bit. Bit 0 corresponds to channel 0, bit 1 corresponds to channel 1, and so on.
Writing a 1 to a bit assigns the according channel to the low priority queue.
Read: The corresponding channel is assigned to the low priority queue.
Write: No effect.
Read: The corresponding channel is assigned to the high priority queue.
Write: The corresponding channel is assigned to the low priority queue.
