Texas Instruments TMS570LC4357 Technical Reference Manual page 813

www.ti.com
Table 21-15. Description of the Asynchronous m Configuration Register (CEnCFG) (continued)
Parameter
ASIZE
Table 21-16. Description of the Asynchronous Wait Cycle Configuration Register (AWCC)
Parameter
WPn
MAX_EXT_WAIT
Table 21-17. Description of the EMIF Interrupt Mask Set Register (INTMSKSET)
Parameter
WR_MASK_SET
AT_MASK_SET
Table 21-18. Description of the EMIF Interrupt Mast Clear Register (INTMSKCLR)
Parameter
WR_MASK_CLR
AT_MASK_CLR
SPNU563A – March 2018
Submit Documentation Feedback
Description
Asynchronous Device Bus Width.
This field determines the data bus width of the asynchronous interface in the following way:
• ASIZE = 0 selects an 8-bit bus
• ASIZE = 1 selects a 16-bit bus
The configuration of ASIZE determines the function of the EMIF_A and EMIF_BA pins as
described in Section 21.2.6.1. This field also determines the number of external accesses
required to fulfill a request generated by one of the sources mentioned in
example, a request for a 32-bit word would require four external access when ASIZE = 0. Refer to
the datasheet of the external asynchronous device to determine the appropriate setting for this
field.
Description
EM_WAIT Polarity.
• WPn = 0 selects active-low polarity
• WPn = 1 selects active-high polarity
When set to 1, the EMIF will wait if the EMIF_nWAIT pin is high. When cleared to 0, the EMIF will
wait if the EMIF_nWAIT pin is low. The EMIF must have the Extended Wait Mode enabled for the
EMIF_nWAIT pin to affect the width of the strobe period.
Maximum Extended Wait Cycles.
This field configures the number of EMIF clock cycles the EMIF will wait for the EMIF_nWAIT pin
to be deactivated during the strobe period of an access cycle. The maximum number of EMIF
clock cycles it will wait is determined by the following formula:
Maximum Extended Wait Cycles = (MAX_EXT_WAIT + 1) × 16
If the EMIF_nWAIT pin is not deactivated within the time specified by this field, the EMIF resumes
the access cycle, registering whatever data is on the bus and proceeding to the hold period of the
access cycle. This situation is referred to as an Asynchronous Timeout. An Asynchronous
Timeout generates an interrupt, if it has been enabled in the EMIF interrupt mask set register
(INTMSKSET). Refer to Section 21.2.9.1
Description
Wait Rise Mask Set.
Writing a 1 enables an interrupt to be generated when a rising edge on EMIF_nWAIT occurs
Asynchronous Timeout Mask Set.
Writing a 1 to this bit enables an interrupt to be generated when an Asynchronous Timeout
occurs.
Description
Wait Rise Mask Clear.
Writing a 1 to this bit disables the interrupt, clearing the WR_MASK_SET bit in the EMIF interrupt
mask set register (INTMSKSET).
Asynchronous Timeout Mask Clear.
Writing a 1 to this bit prevents an interrupt from being generated when an Asynchronous Timeout
occurs.
Copyright © 2018, Texas Instruments Incorporated
EMIF Module Architecture
for more information about the EMIF interrupts.
External Memory Interface (EMIF)
Section 21.2.2. For
813
