16.4.13 ESM Low-Time Counter Register (ESMLTCR)

Figure 16-23. ESM Low-Time Counter Register (ESMLTCR) [offset = 30h]
31
15
LEGEND: R = Read only; -n = value after reset
Table 16-15. ESM Low-Time Counter Register (ESMLTCR) Field Descriptions
Bit Field
31-16 Reserved
15-0 LTC

16.4.14 ESM Low-Time Counter Preload Register (ESMLTCPR)

Figure 16-24. ESM Low-Time Counter Preload Register (ESMLTCPR) [offset = 34h]
31
15 14 13
LTCP
R/WP-0
LEGEND: R/W = Read/Write; R = Read; WP = Write in privileged mode only; -n = value after reset
Table 16-16. ESM Low-Time Counter Preload Register (ESMLTCPR) Field Descriptions
Bit Field
31-16 Reserved
15-0 LTCP
SPNU563A – March 2018
Submit Documentation Feedback
Value Description
0 Reads return 0. Writes have no effect.
ERROR Pin Low-Time Counter
16-bit pre-loadable down-counter to control low-time of ERROR pin. The low-time counter is
triggered by the peripheral clock (VCLK).
Note: Low time counter is set to the default pre-load value of the ESMLTCPR in the following
cases:
1. Reset (power on reset or warm reset)
2. An error occurs
3. User forces an error
Value Description
0 Reads return 0. Writes have no effect.
ERROR Pin Low-Time Counter Pre-load Value
16-bit pre-load value for the ERROR pin low-time counter.
Note: Only LTCP.15 and LTCP.14 are configurable (privileged mode write).
Copyright © 2018, Texas Instruments Incorporated
Reserved
R-0
LTC
R-3FFFh
Reserved
R-0
LTCP
R-3FFFh
ESM Control Registers
Error Signaling Module (ESM)
16
0
16
0
