Control Registers

13.3.8 CCM-R5F Status Register 4 (CCMSR4)

Figure 13-10. CCM-R5F Status Register 4 (CCMSR4) (Offset = 1Ch)
31
15
Reserved
R-0
LEGEND: R/W = Read/Write; R = Read only; W1CP = Write 1 to clear in privilege mode only; -n = value after reset
Table 13-15. CCM-R5F Status Register 4 (CCMSR4) Field Descriptions
Bit Field
31-17 Reserved
16 CMPE4
15-9 Reserved
8 STC4
7-2 Reserved
1 STET4
0 STE4
514
CPU Compare Module for Cortex-R5F (CCM-R5F)
Reserved
R-0
9
Value Description
0 Reads return 0. Writes have no effect.
Compare Error for Power Domain Inactivity Monitor.
Read in User and Privileged mode. Write in Privileged mode only.
0 Read: CPU signals are identical.
Write: Leaves the bit unchanged.
1 Read: CPU signal compare mismatch.
Write: Clears the bit.
Reads return 0. Writes have no effect.
Self-test Complete for Power Domain Inactivity Monitor.
Note: This bit is always 0 when not in self-test mode. Once set, switching from self-test mode to
other modes will clear this bit.
Read/Write in User and Privileged mode.
0 Read: Self-test on-going if self-test mode is entered.
Write: Writes have no effect.
1 Read: Self-test is complete.
Write: Writes have no effect.
Reads return 0. Writes have no effect.
Self-test Error Type for Power Domain Inactivity Monitor.
Read/Write in User and Privileged mode.
0 Read: Self-test failed during Compare Match Test if STE4 = 1.
Write: Writes have no effect.
1 Read: Self-test failed during Compare Mismatch Test if STE4 = 1.
Write: Writes have no effect.
Self-test Error for Power Domain Inactivity Monitor.
Note: This bit gets updated when the self-test is complete or an error is detected.
Read/Write in User and Privileged mode.
0 Read: Self-test passed.
Write: Writes have no effect.
1 Read: Self-test failed.
Write: Writes have no effect.
Copyright © 2018, Texas Instruments Incorporated
8 7
STC4 Reserved
R-0
17
2
STET4
R-0 R-0
SPNU563A – March 2018
Submit Documentation Feedback
www.ti.com
16
CPME4
R/W1CP-0
1 0
STE4
R-0
