10.8.12 STC Clock Prescalar Register (STCCLKDIV)

This register is described in
each segment. STCCLK is derived from the system clock (GCLK1 for STC1 and VCLK2 for STC2) and
the configured ratio is applied when the corresponding segment is under test. The division ratio
programmed in this register will have effect only when the value in the CLKDIV field of the STCLKDIV
register (FFFF E108h) from SYS2 module is zero. Else the division ratio will be taken from SYS2. This is
done for software compatibility.
NOTE: The clock divider ratio is applied when the corresponding segment is under test.
Figure 10-25. STC Clock Prescalar Register (STCCLKDIV) [offset = 44h]
31
Reserved
R-0
15
LEGEND: R/W = Read/Write; R = Read only; WP = Write in privilege mode only; -n = value after nPORST (power on reset) or System reset
Table 10-20. STC Clock Prescalar Register (STCCLKDIV) Field Descriptions
Bit Field
31-27 Reserved
26-24 CLKDIV0
23-19 Reserved
18-16 CLKDIV1
15-0 Reserved
456
Self-Test Controller (STC) Module
Figure 10-25. This register is used to configure STC clock divider ratio for
27 26
CLKDIV0
R/WP-0
Value Description
0 Reads return 0. Writes have no effect.
STCCLK divider for segment 0.
0-7h Division ratio of segment 0 will be n+1. STCCLK clock will be divided by (n+1) for segment 0.
0 Reads return 0. Writes have no effect.
STCCLK divider for segment 1.
0-7h Division ratio of segment 1 will be n+1. STCCLK clock will be divided by (n+1) for segment 1.
0 Reads return 0. Writes have no effect.
Copyright © 2018, Texas Instruments Incorporated
24 23
Reserved
R-0
Reserved
R-0
www.ti.com
19 18 16
CLKDIV1
R/WP-0
0
SPNU563A – March 2018
