3.4.2 SCM Control Register (SCMCNTRL)

31 28
Reserved
R-0
15 12
Reserved
R-0
LEGEND: R/W = Read/Write; R = Read only; WP = Write in privileged mode only; -n = value after synchronous reset on system reset
Bit Field
31-28 Reserved
27-24 PAR DIAG EN
23-20 Reserved
19-16 GLOBAL_ERROR_CLR
15-12 Reserved
11-8 DTC_SOFT_RESET
7-4 Reserved
3-0 TO_CLEAR
SPNU563A – March 2018
Submit Documentation Feedback
Figure 3-6. SCM Control Register (SCMCNTRL) [offset = 04h]
27
PAR DIAG EN
R/WP-5h
11
DTC_SOFT_RESET
R/WP-5h
Table 3-3. SCM Control Register (SCMCNTRL) Field Descriptions
Value Description
0 Reserved. Reads return 0.
Sticky key write values of Ah. Writing Ah sends out an active-high "pulse" to the SCR
and resets the key back to 5h.
Read:
5h Sticky key.
All other values Reserved
Write in Privilege:
Ah Parity diagnostic enable.
All other values Reserved
0 Reserved. Reads return 0.
Clear global error in interconnect. Writing Ah sends out a clear pulse to the SCR and
resets the key back to 5h.
Read:
5h Sticky key.
All other values Reserved
Write in Privilege:
Ah Enable global error clear.
All other values Reserved
0 Reserved. Reads return 0.
Diagnostic self-test error enable. Writing Ah forces the SCM to initiate self-test
sequence. The hardware will reset the key back to 0x5 whenever self-test is
completed.
Read:
5h Sticky key.
All other values Reserved
Write in Privilege:
Ah Enable sequence to start interconnect self-test.
All other values Reserved
0 Reserved. Reads return 0.
Clear real time counters inside SCR. Writing Ah sends out a clear pulse to the SCR
and resets the key back to 5h.
Read:
5h Sticky key.
All other values Reserved
Write in Privilege:
Ah Enable global error clear.
All other values Reserved
