Texas Instruments TMS570LC4357 Technical Reference Manual page 741

www.ti.com
20.3.1.23 Port Assignment Register 2 (PAR2)
31 30 28
Rsvd CH0PA
R-0 R/WP-0
15 14 12
Rsvd CH4PA
R-0 R/WP-0
LEGEND: R/W = Read/Write; R = Read only; WP = Write in privilege mode only; -n = value after reset
Table 20-31. Port Assignment Register 2 (PAR2) Field Descriptions
Bit Field Value
31 Reserved 0
30-28 CH16PA
1h
2h
3h
Others
27 Reserved 0
26-24 CH17PA 0-7h
23 Reserved 0
22-20 CH18PA 0-7h
19 Reserved 0
18-16 CH19PA 0-7h
15 Reserved 0
14-12 CH20PA 0-7h
11 Reserved 0
10-8 CH21PA 0-7h
7 Reserved 0
6-4 CH22PA 0-7h
3 Reserved 0
2-0 CH23PA 0-7h
SPNU563A – March 2018
Submit Documentation Feedback
Figure 20-41. Port Assignment Register 2 (PAR2) [offset = 9Ch]
27 26
Rsvd CH1PA
R-0 R/WP-0
11 10
Rsvd CH5PA
R-0 R/WP-0
Description
Reads return 0. Writes have no effect.
These bit fields determine to which port(s) channel 16 is assigned.
Port A and B combined, A read/B write
Port A only
Port B only
Port A and B combined, B read/A write
Reads return 0. Writes have no effect.
These bit fields determine to which port channel 17 is assigned. Refer to CH16PA for bit value
descriptions.
Reads return 0. Writes have no effect.
These bit fields determine to which port channel 18 is assigned. Refer to CH16PA for bit value
descriptions.
Reads return 0. Writes have no effect.
These bit fields determine to which port channel 19 is assigned. Refer to CH16PA for bit value
descriptions.
Reads return 0. Writes have no effect.
These bit fields determine to which port channel 20 is assigned. Refer to CH16PA for bit value
descriptions.
Reads return 0. Writes have no effect.
These bit fields determine to which port channel 21 is assigned. Refer to CH16PA for bit value
descriptions.
Reads return 0. Writes have no effect.
These bit fields determine to which port channel 22 is assigned. Refer to CH16PA for bit value
descriptions.
Reads return 0. Writes have no effect.
These bit fields determine to which port channel 23 is assigned. Refer to CH16PA for bit value
descriptions.
Copyright © 2018, Texas Instruments Incorporated
24 23 22
Rsvd CH2PA
R-0 R/WP-0
8 7 6
Rsvd CH6PA
R-0 R/WP-0
Direct Memory Access Controller (DMA) Module
Control Registers and Control Packets
20 19 18
Rsvd CH3PA
R-0 R/WP-0
4 3 2
Rsvd CH7PA
R-0 R/WP-0
16
0
741
