System and Peripheral Control Registers
2.5.1.23 MSTC Global Status Register (MSTCGSTAT)
The MSTCGSTAT register, shown in
memory hardware initialization and the memory self-test.
Figure 2-30. MSTC Global Status Register (MSTCGSTAT) (offset = 68h)
31
15
Reserved
R-0
LEGEND: R/W = Read/Write; R = Read only; C = Clear; WP = Write in privileged mode only; -n = value after reset
Table 2-42. MSTC Global Status Register (MSTCGSTAT) Field Descriptions
Bit Field Value
31-9 Reserved 0
8 MINIDONE
0
1
7-1 Reserved 0
0 MSTDONE
0
1
174
Architecture
Figure 2-30
Reserved
9 8
MINIDONE
R/WPC-0
Description
Reads return 0. Writes have no effect.
Memory hardware initialization complete status.
Note: Disabling the MINITGENA key (By writing from a Ah to any other value) will clear the
MINIDONE status bit to 0.
Note: Individual memory initialization status is shown in the MINISTAT register.
Read: Memory hardware initialization is not complete for all memory.
Write: A write of 0 has no effect.
Read: Hardware initialization of all memory is completed.
Write: The bit is cleared to 0.
Reads return 0. Writes have no effect.
Memory self-test run complete status.
Note: Disabling the MSTGENA key (by writing from a Ah to any other value) will clear the
MSTDONE status bit to 0.
Read: Memory self-test is not completed.
Write: A write of 0 has no effect.
Read: Memory self-test is completed.
Write: The bit is cleared to 0.
Copyright © 2018, Texas Instruments Incorporated
and described in Table 2-42, shows the status of the
R-0
7
Reserved
R-0
www.ti.com
16
1 0
MSTDONE
R/WP-0
