20.3.1.63 DMA ECC Error Address Register (DMAPAR)
Figure 20-80. DMA ECC Error Address Register (DMAPAR) [offset = 1ACh]
31
Reserved
R-0
15 12
Reserved
R-0
LEGEND: R/W = Read/Write; R = Read only; W1C = Write 1 to clear; X= value is undefined; -n = value after reset
Table 20-70. DMA ECC Error Address Register (DMAPAR) Field Descriptions
Bit Field
31-25 Reserved
24 EDFLAG
23-12 Reserved
11-0 ERRORADDRESS
SPNU563A – March 2018
Submit Documentation Feedback
25
EDFLAG
R/W1C-0
11
Value Description
0 Reads return 0. Writes have no effect.
ECC Error Detection Flag. This flag indicates if an ECC error occurred on reading DMA Control
packet RAM.
0 Read: No error occurred.
Write: No effect.
1 Read: Error detected and the address is captured in DMAPAR's ERROR_ADDRESS field.
Write: Clears the bit.
0 Reads return 0. Writes have no effect.
0-FFFh Error address. These bits hold the address of the first ECC error generated in the RAM. This
error address is frozen from being updated until it is read by the CPU. During emulation mode
when SUSPEND is high, this address is frozen even when read.
Note: The error address register will not be reset by PORRST nor by any other reset
source.
Copyright © 2018, Texas Instruments Incorporated
Control Registers and Control Packets
24 23
ERRORADDRESS
R-X
Direct Memory Access Controller (DMA) Module
16
Reserved
R-0
0
