Configuration
CLI Quick
Configuration
Step-by-Step
Procedure
Results
To quickly create and configure virtual routing instances, copy the following commands
and paste them into the switch terminal window:
[edit]
set interfaces ge-0/0/3 vlan-tagging
set interfaces ge-0/0/3 unit 0 vlan-id 1030 family inet address 103.1.1.1/24
set interfaces ge-0/0/3 unit 1 vlan-id 1031 family inet address 103.1.1.1/24
set routing-instances r1 instance-type virtual-router
set routing-instances r1 interface ge-0/0/1.0
set routing-instances r1 interface ge-0/0/3.0
set routing-instances r2 instance-type virtual-router
set routing-instances r2 interface ge-0/0/2.0
set routing-instances r2 interface ge-0/0/3.1
To configure virtual routing instances:
Create a VLAN-tagged interface:
1.
[edit]
user@switch# set interfaces ge-0/0/3 vlan-tagging
Create two subinterfaces, on the interface, one for each routing instance:
2.
[edit]
user@switch# set interfaces ge-0/0/3 unit 0 vlan-id 1030 family inet address 103.1.1.1/24
user@switch# set interfaces ge-0/0/3 unit 1 vlan-id 1031 family inet address 103.1.1.1/24
Create two virtual routers:
3.
[edit]
user@switch# set routing-instances r1 instance-type virtual-router
user@switch# set routing-instances r2 instance-type virtual-router
Set the interfaces for the virtual routers:
4.
[edit]
user@switch# set routing-instances r1 interface ge-0/0/1.0
user@switch# set routing-instances r1 interface ge-0/0/3.0
user@switch# set routing-instances r2 interface ge-0/0/2.0
user@switch# set routing-instances r2 interface ge-0/0/3.1
Check the results of the configuration:
user@switch> show configuration
interfaces {
ge-0/0/1 {
unit 0 {
family ethernet-switching;
}
}
ge-0/0/2 {
unit 0 {
family ethernet-switching;
}
