Dell PowerConnect J-Series Ethernet Switch Complete Software Guide for Junos OS
Table 116: show virtual-chassis vc-port statistics Output Fields (continued)
Field Name Field Description
Jabber packets Number of packets received on the VCP interface that were longer than
1518 octets—excluding framing bits, but including FCS octets—and that had
either an FCS error or an alignment error.
NOTE: This definition of jabber is different from the definition in IEEE-802.3
section 8.2.1.5 (10Base5) and section 10.3.1.4 (10Base2). These documents
define jabber as the condition in which any packet exceeds 20 ms. The allowed
range to detect jabber is between 20 ms and 150 ms.
Number of packets received on the VCP interface that were shorter than
Fragments received
64 octets (excluding framing bits, but including FCS octets), and had either an
FCS error or an alignment error.
Fragment frames normally increment because both runts (which are normal
occurrences caused by collisions) and noise hits are counted.
Number of outbound packets received on the VCP interface that could not be
Ifout errors
transmitted because of errors.
Number of outbound packets received on the VCP interface that were dropped,
Packet drop events
rather than being encapsulated and sent out of the switch as fragments. The
packet drop counter is incremented if a temporary shortage of packet memory
causes packet fragmentation to fail.
64 octets frames Number of packets received on the VCP interface (including invalid packets)
that were 64 octets in length (excluding framing bits, but including FCS octets).
Number of packets received on the VCP interface (including invalid packets)
65–127 octets frames
that were between 65 and 127 octets in length, inclusive (excluding framing
bits, but including FCS octets).
128–255 octets Number of packets received on the VCP interface (including invalid packets)
that were between 128 and 255 octets in length, inclusive (excluding framing
frames
bits, but including FCS octets).
256–511 octets Number of packets received on the VCP interface (including invalid packets)
that were between 256 and 511 octets in length, inclusive (excluding framing
frames
bits, but including FCS octets).
512–1023 octets Number of packets received on the VCP interface (including invalid packets)
that were between 512 and 1023 octets in length, inclusive (excluding framing
frames
bits, but including FCS octets).
Number of packets received on the VCP interface (including invalid packets)
1024–1518 octets
that were between 1024 and 1518 octets in length, inclusive (excluding framing
frames
bits, but including FCS octets).
Number of packets per second received and transmitted on the VCP interface.
Rate packets per
second
Number of bytes per second received and transmitted on the VCP interface.
Rate bytes per
second
856
Level of Output
detail extensive
detail extensive
detail extensive
detail extensive
detail extensive
detail extensive
detail extensive
detail extensive
detail extensive
detail extensive
detail extensive
detail extensive
