(CLI-config)# bootimage upgrade odu
9) A reboot of the radio is required to load the new image after upgrade
(CLI-config)# reboot
The upgrade time varies depending upon the images and the size of the image.
The firmware can be verified by logging into the radio via the CLI through the version
command or Web browser version page under the Firmware Version section.
The Current firmware is the currently running firmware. The firmware which was
replaced will be located in the previous images.

Upgrade Procedure -FTP

To perform the firmware upgrade using FTP, use the ftp command to load the images
into memory, then the bootimage upgrade commands just as with the TFTP method.
The FTP method is much faster and has built in error checking.
All that is needed is the IP address of the ftp server, a username/password, and the
filename to be uploaded. The new file to be uploaded should be placed on the server.
The ftp server will prompt for the password before allowing access.
1) Put the new software files on the ftp server using the ftp put command from a
local computer (these commands are not done from the Trango equipment).
ftp> put <source file> <destination>:
The <source> will be the filename only. The <destination> will include both path and file
name.
2) After putting the file onto the server, log into the GigaPlus and run the ftp
command from the command line as follows to open access to the server:
ftp <server_ip> <user_name>
password: xxxxxxx
If prompted for the password multiple times, check the connectivity to the
server by pinging the FTP server IP address from the debug prompt.
3) Next , get the file from the FTP server by typing the get command from the ftp
prompt.
ftp> get <file_name>
