Outdoor Unit
Part Numbers
HP ODUs, – 13 GHZ
HP2-13-0225-1A ODU, HP2 13Ghz, ANSI TR225, 1A
HP2-13-0225-1B ODU, HP2 13Ghz, ANSI TR225, 1B
HP2-13-0225-2A ODU, HP2 13Ghz, ANSI TR225, 2A
HP2-13-0225-2B ODU, HP2 13Ghz, ANSI TR225, 2B
HP2-13-0225-3A ODU, HP2 13Ghz, ANSI TR225, 3A
HP2-13-0225-3B ODU, HP2 13Ghz, ANSI TR225, 3B
HP2-13-0266-1A ODU, HP2 13Ghz, ETSI TR266, 1A
HP2-13-0266-1B ODU, HP2 13Ghz, ETSI TR266, 1B
HP2-13-0266-2A ODU, HP2 13Ghz, ETSI TR266, 2A
HP2-13-0266-2B ODU, HP2 13Ghz, ETSI TR266, 2B
HP2-13-0266-3A ODU, HP2 13Ghz, ETSI TR266, 3A
HP2-13-0266-3B ODU, HP2 13Ghz, ETSI TR266, 3B
HP2-13-0266-4A ODU, HP2 13Ghz, ETSI TR266, 4A
HP2-13-0266-4B ODU, HP2 13Ghz, ETSI TR266, 4B
HP1-13-0266-1A ODU, HP 13Ghz, ETSI TR266, 1A
HP1-13-0266-1B ODU, HP 13Ghz, ETSI TR266, 1B
HP1-13-0266-2A ODU, HP 13Ghz, ETSI TR266, 2A
HP1-13-0266-2B ODU, HP 13Ghz, ETSI TR266, 2B
HP1-13-0266-3A ODU, HP 13Ghz, ETSI TR266, 3A
HP1-13-0266-3B ODU, HP 13Ghz, ETSI TR266, 3B
HP1-13-0266-4A ODU, HP 13Ghz, ETSI TR266, 4A
HP1-13-0266-4B ODU, HP 13Ghz, ETSI TR266, 4B
HP ODUs, – 15 GHZ
HP2-15-0315-1A ODU, HP2 15Ghz, ETSI TR315, 1A
HP2-15-0315-1B ODU, HP2 15Ghz, ETSI TR315, 1B
HP2-15-0315-2A ODU, HP2 15Ghz, ETSI TR315, 2A
HP2-15-0315-2B ODU, HP2 15Ghz, ETSI TR315, 2B
HP2-15-0315-3A ODU, HP2 15Ghz, ETSI TR315, 3A
HP2-15-0315-3B ODU, HP2 15Ghz, ETSI TR315, 3B
HP1-15-0315-1A ODU, HP 15Ghz, ETSI TR315, 1A
HP1-15-0315-1B ODU, HP 15Ghz, ETSI TR315, 1B
HP1-15-0315-2A ODU, HP 15Ghz, ETSI TR315, 2A
HP1-15-0315-2B ODU, HP 15Ghz, ETSI TR315, 2B
HP1-15-0315-3A ODU, HP 15Ghz, ETSI TR315, 3A
HP1-15-0315-3B ODU, HP 15Ghz, ETSI TR315, 3B
HP2-15-0420-4A ODU, HP2 15Ghz, ETSI TR420, 4A
HP2-15-0420-4B ODU, HP2 15Ghz, ETSI TR420, 4B
HP2-15-0420-5A ODU, HP2 15Ghz, ETSI TR420, 5A
HP2-15-0420-5B ODU, HP2 15Ghz, ETSI TR420, 5B
HP2-15-0420-6A ODU, HP2 15Ghz, ETSI TR420, 6A
HP2-15-0420-6B ODU, HP2 15Ghz, ETSI TR420, 6B
HP2-15-0420-7A ODU, HP2 15Ghz, ETSI TR420, 7A
HP2-15-0420-7B ODU, HP2 15Ghz, ETSI TR420, 7B
HP1-15-0420-4A ODU, HP 15Ghz, ETSI TR420, 4A
HP1-15-0420-4B ODU, HP 15Ghz, ETSI TR420, 4B
HP1-15-0420-5A ODU, HP 15Ghz, ETSI TR420, 5A
HP1-15-0420-5B ODU, HP 15Ghz, ETSI TR420, 5B
HP1-15-0420-6A ODU, HP 15Ghz, ETSI TR420, 6A
HP1-15-0420-6B ODU, HP 15Ghz, ETSI TR420, 6B
HP1-15-0420-7A ODU, HP 15Ghz, ETSI TR420, 7A
HP1-15-0420-7B ODU, HP 15Ghz, ETSI TR420, 7B
Trango Systems, Inc.
Description
GigaPlus User Manual Rev 3.1
TX Freq TX Freq Diplexer
Min* Max* Range
(MHz) (MHz) (MHz)
12,700 12,815 115
12,925 13,040 115
12,755 12,870 115
12,980 13,095 115
12,810 12,925 115
13,035 13,150 115
12,751 12,814 63
13,017 13,080 63
12,807 12,870 63
13,073 13,136 63
12,863 12,926 63
13,129 13,192 63
12,919 12,982 63
13,185 13,248 63
12,751 12,814 63
13,017 13,080 63
12,807 12,870 63
13,073 13,136 63
12,863 12,926 63
13,129 13,192 63
12,919 12,982 63
13,185 13,248 63
14,627 14,732 105
14,942 15,047 105
14,725 14,844 119
15,040 15,159 119
14,823 14,928 105
15,138 15,243 105
14,627 14,746 119
14,942 15,061 119
14,725 14,844 119
15,040 15,159 119
14,823 14,942 119
15,138 15,257 119
14,501 14,613 112
14,921 15,033 112
14,606 14,725 119
15,026 15,145 119
14,718 14,837 119
15,138 15,257 119
14,816 14,928 112
15,236 15,348 112
14,501 14,613 112
14,921 15,033 112
14,606 14,725 119
15,026 15,145 119
14,718 14,837 119
15,138 15,257 119
14,816 14,928 112
15,236 15,348 112
Max
Chan
Size
(MHz)
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
236
