Outdoor Unit
Part Numbers
HP1-15-0728-1A ODU, HP 15Ghz, ETSI TR728, 1A
HP1-15-0728-1B ODU, HP 15Ghz, ETSI TR728, 1B
HP1-15-0728-2A ODU, HP 15Ghz, ETSI TR728, 2A
HP1-15-0728-2B ODU, HP 15Ghz, ETSI TR728, 2B
HP2-15-0728-1A ODU, HP2 15Ghz, ETSI TR728, 1A
HP2-15-0728-1B ODU, HP2 15Ghz, ETSI TR728, 1B
HP ODUs, – 18 GHZ
HP2-18-1010-1A ODU, HP2 18Ghz, ETSI TR1010/1008, 1A
HP2-18-1010-1B ODU, HP2 18Ghz, ETSI TR1010/1008, 1B
HP2-18-1010-2A ODU, HP2 18Ghz, ETSI TR1010/1008, 2A
HP2-18-1010-2B ODU, HP2 18Ghz, ETSI TR1010/1008, 2B
HP2-18-1010-3A ODU, HP2 18Ghz, ETSI TR1010/1008, 3A
HP2-18-1010-3B ODU, HP2 18Ghz, ETSI TR1010/1008, 3B
HP2-18-1010-4A ODU, HP2 18Ghz, ETSI TR1010/1008, 4A
HP2-18-1010-4B ODU, HP2 18Ghz, ETSI TR1010/1008, 4B
HP1-18-1010-1A ODU, HP 18Ghz, ETSI TR1010/1008, 1A
HP1-18-1010-1B ODU, HP 18Ghz, ETSI TR1010/1008, 1B
HP1-18-1010-2A ODU, HP 18Ghz, ETSI TR1010/1008, 2A
HP1-18-1010-2B ODU, HP 18Ghz, ETSI TR1010/1008, 2B
HP1-18-1010-3A ODU, HP 18Ghz, ETSI TR1010/1008, 3A
HP1-18-1010-3B ODU, HP 18Ghz, ETSI TR1010/1008, 3B
HP1-18-1010-4A ODU, HP 18Ghz, ETSI TR1010/1008, 4A
HP1-18-1010-4B ODU, HP 18Ghz, ETSI TR1010/1008, 4B
HP1-18-1092-1A ODU, HP 18Ghz, ETSI TR1092, 1A
HP1-18-1092-1B ODU, HP 18Ghz, ETSI TR1092, 1B
HP1-18-1092-2A ODU, HP 18Ghz, ETSI TR1092, 2A
HP1-18-1092-2B ODU, HP 18Ghz, ETSI TR1092, 2B
HP1-18-1092-3A ODU, HP 18Ghz, ETSI TR1092, 3A
HP1-18-1092-3B ODU, HP 18Ghz, ETSI TR1092, 3B
HP2-18-1560-3A ODU, HP2 18Ghz, ANSI TR1560, 3A
HP2-18-1560-3B ODU, HP2 18Ghz, ANSI TR1560, 3B
HP1-18-1560-3A ODU, HP 18Ghz, ANSI TR1560, 3A
HP1-18-1560-3B ODU, HP 18Ghz, ANSI TR1560, 3B
Trango Systems, Inc.
Description
GigaPlus User Manual Rev 3.1
TX Freq TX Freq Diplexer
Min* Max* Range
(MHz) (MHz) (MHz)
14,500 14,615 115
15,228 15,343 115
14,500 14,625 125
15,228 15,353 125
14,500 14,615 115
15,228 15,343 115
17,685 17,985 300
18,695 18,995 300
17,930 18,230 300
18,940 19,240 300
18,180 18,480 300
19,190 19,490 300
18,400 18,700 300
19,410 19,710 300
17,685 17,985 300
18,695 18,995 300
17,930 18,230 300
18,940 19,240 300
18,180 18,480 300
19,190 19,490 300
18,400 18,700 300
19,410 19,710 300
17,700 18,060 360
18,805 19,165 360
17,975 18,335 360
19,080 19,440 360
18,235 18,595 360
19,340 19,700 360
17,700 18,140 440
19,260 19,700 440
17,700 18,140 440
19,260 19,700 440
Max
Chan
Size
(MHz)
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
