Outdoor Unit
Part Numbers
HP ODUs, – 23 GHZ
HP2-23-1008-1A ODU, HP2 23Ghz, ETSI TR1008, 1A
HP2-23-1008-1B ODU, HP2 23Ghz, ETSI TR1008, 1B
HP2-23-1008-2A ODU, HP2 23Ghz, ETSI TR1008, 2A
HP2-23-1008-2B ODU, HP2 23Ghz, ETSI TR1008, 2B
HP1-23-1008-1A ODU, HP 23Ghz, ETSI TR1008, 1A
HP1-23-1008-1B ODU, HP 23Ghz, ETSI TR1008, 1B
HP1-23-1008-2A ODU, HP 23Ghz, ETSI TR1008, 2A
HP1-23-1008-2B ODU, HP 23Ghz, ETSI TR1008, 2B
HP2-23-1200-5A ODU, HP2 23Ghz, ANSI TR1200, 5A
HP2-23-1200-5B ODU, HP2 23Ghz, ANSI TR1200, 5B
HP2-23-1200-6A ODU, HP2 23Ghz, ANSI TR1200, 6A
HP2-23-1200-6B ODU, HP2 23Ghz, ANSI TR1200, 6B
HP2-23-1200-7A ODU, HP2 23Ghz, ANSI TR1200, 7A
HP2-23-1200-7B ODU, HP2 23Ghz, ANSI TR1200, 7B
HP1-23-1200-5A ODU, HP 23Ghz, ANSI TR1200, 5A
HP1-23-1200-5B ODU, HP 23Ghz, ANSI TR1200, 5B
HP1-23-1200-6A ODU, HP 23Ghz, ANSI TR1200, 6A
HP1-23-1200-6B ODU, HP 23Ghz, ANSI TR1200, 6B
HP1-23-1200-7A ODU, HP 23Ghz, ANSI TR1200, 7A
HP1-23-1200-7B ODU, HP 23Ghz, ANSI TR1200, 7B
HP2-23-1232-1A ODU, HP2 23Ghz, ETSI TR1232, 1A
HP2-23-1232-1B ODU, HP2 23Ghz, ETSI TR1232, 1B
HP2-23-1232-2A ODU, HP2 23Ghz, ETSI TR1232, 2A
HP2-23-1232-2B ODU, HP2 23Ghz, ETSI TR1232, 2B
HP2-23-1232-3A ODU, HP2 23Ghz, ETSI TR1232, 3A
HP2-23-1232-3B ODU, HP2 23Ghz, ETSI TR1232, 3B
HP2-23-1232-4A ODU, HP2 23Ghz, ETSI TR1232, 4A
HP2-23-1232-4B ODU, HP2 23Ghz, ETSI TR1232, 4B
HP1-23-1232-1A ODU, HP 23Ghz, ETSI TR1232, 1A
HP1-23-1232-1B ODU, HP 23Ghz, ETSI TR1232, 1B
HP1-23-1232-2A ODU, HP 23Ghz, ETSI TR1232, 2A
HP1-23-1232-2B ODU, HP 23Ghz, ETSI TR1232, 2B
HP1-23-1232-3A ODU, HP 23Ghz, ETSI TR1232, 3A
HP1-23-1232-3B ODU, HP 23Ghz, ETSI TR1232, 3B
HP1-23-1232-4A ODU, HP 23Ghz, ETSI TR1232, 4A
HP1-23-1232-4B ODU, HP 23Ghz, ETSI TR1232, 4B
Trango Systems, Inc.
Description
GigaPlus User Manual Rev 3.1
TX Freq TX Freq Diplexer
Min* Max* Range
(MHz) (MHz) (MHz)
22,000 22,314 314
23,008 23,322 314
22,286 22,600 314
23,294 23,608 314
21,994 22,330 336
23,002 23,338 336
22,274 22,610 336
23,282 23,618 336
21,200 21,600 400
22,400 22,800 400
21,600 22,000 400
22,800 23,200 400
22,000 22,400 400
23,200 23,600 400
21,200 21,600 400
22,400 22,800 400
21,600 22,000 400
22,800 23,200 400
22,000 22,400 400
23,200 23,600 400
21,200 21,500 300
22,432 22,732 300
21,472 21,786 314
22,704 23,018 314
21,779 22,093 314
23,011 23,325 314
22,086 22,386 300
23,318 23,618 300
21,200 21,500 300
22,432 22,732 300
21,472 21,786 314
22,704 23,018 314
21,779 22,093 314
23,011 23,325 314
22,086 22,386 300
23,318 23,618 300
Max
Chan
Size
(MHz)
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
