Subnet Mask:
Gateway IP:
ETH1 MAC:
ETH2 MAC:
Step 3: Turn the ODU Section of the radio on
Type odupower on to apply power to the Radio section of the unit. After the CLI returns
the status of "on", enter model to show the models, serial numbers, TR spacing and
transmit frequency range of the unit.
(CLI-config)# odupower on
ODU Power enable:
SUCCESS
(CLI-config)# model
IDU Model:
IDU Serial ID:
ODU Model:
ODU Serial ID:
Tx Freq Min:
Tx Freq Max:
Freq Duplex:
Step 4: Set the Transmitter and Receiver Center frequency
The center frequency must be within the min and max shown in the model command
and must be at least ½ of the occupied transmitter bandwidth away from the limits for
proper operation.
Enter the transmit frequency in MHz (the resolution of the frequency is .250 MHz). The
receive frequency will automatically be programmed as follows:
For A models, RX Freq = TX freq + Freq Duplex.
For B models, RX Freq= TX Freq – Freq Duplex.
Trango Systems, Inc.
255.255.254.0
10.14.0.1
00:01:de:81:65:44
00:01:de:81:65:45
on
IDU-GigaPlus-1
8480068
HP2-23-1200-3A
C110301327
22000.00
22400.00
1200.00 (MHz)
