Preface

This manual covers the basic configuration and installation of the TrangoLINK
licensed microwave backhaul system,
This document is intended to instruct and assist personnel in the operation, installation
and maintenance of the TrangoLINK
accessories shown in Table 1.
It is recommended that all personnel engaged in such activities be properly trained.
Trango Systems disclaims all liability whatsoever, implied or express, for any risk of
damage, loss or reduction in system performance arising directly or indirectly out of the
failure of the customer, or anyone acting on the customer's behalf, to abide by the
instructions, system parameters, or recommendations made in this document.
Part Number
Giga PLUS-IDU-1
HP1-XX-YYYY-ZZ
HP2-XX-YYYY-ZZ
PSUPPLY-DT-48
CBLDAT-RIU3
CBLDAT-RSSI
GigaPlus-KEY-1
GigaPlus-KEY-2
SFP-GigE-C
SFP-GigE-S
SFP-GigE-M
Specific part numbers for radio unit sub-bands and band specific accessories such as
antennas, combiners and remote mounts can be found in Appendix E.
Trango Systems, Inc.
®
GigaPlus microwave backhaul system and related
Description
TrangoLINK™ Giga PLUS Indoor Unit, 100Mbps Full Duplex, ½ rack
mount (All Frequency Versions) ANSI/ETSI
TrangoLINK™ High Power (HP1) Outdoor Unit, 6-40 GHz
TrangoLINK™ High Power (HP2) Outdoor Unit, 6-40 GHz
-48 Volt Universal Desktop Power Supply
1+1 Hot Standby Cable for GigaPlus
BNC-M to Banana plug cable for RSSI voltage measurement
Software Key to Allow Throughputs up to 200Mbps
Software Key to Allow Throughputs up to 375Mbps
SFP 1000BaseT Copper RJ45
SFP Fiber Single Mode Module
SFP Fiber Multi Mode
®

Table 1: TrangoLINK

GigaPlus User Manual Rev 3.1
GigaPlus part numbers
®
