Appendix E – Part Numbers

GigaPlus HP ODU Sub-bands/Tuning Ranges

ODU, Part
Numbers
HP ODUs, 6 GHZ
HP2-06-0160-1A ODU, HP2 6Ghz, ANSI/ETSI TR160/170, 1A - High Band
HP2-06-0160-1B ODU, HP2 6Ghz, ANSI/ETSI TR160/170, 1B - High Band
HP2-06-0160-2A ODU, HP2 6Ghz, ANSI/ETSI TR160/170, 2A - High Band
HP2-06-0160-2B ODU, HP2 6Ghz, ANSI/ETSI TR160/170, 2B - High Band
HP2-06-0160-3A ODU, HP2 6Ghz, ANSI/ETSI TR160/170, 3A - High Band
HP2-06-0160-3B ODU, HP2 6Ghz, ANSI/ETSI TR160/170, 3B - High Band
HP2-06-0160-4A ODU, HP2 6Ghz, ANSI/ETSI TR160/170, 4A - High Band
HP2-06-0160-4B ODU, HP2 6Ghz, ANSI/ETSI TR160/170, 4B - High Band
HP-06-0240-1A ODU, HP 6Ghz,ETSI TR240, 1A - Low Band
HP-06-0240-1B ODU, HP 6Ghz, ETSI TR240, 1B - Low Band
HP-06-0240-2A ODU, HP 6Ghz, ETSI TR240, 2A - Low Band
HP-06-0240-2B ODU, HP 6Ghz, ETSI TR240, 2B - Low Band
HP-06-0240-3A ODU, HP 6Ghz, ETSI TR240, 3A - Low Band
HP-06-0240-3B ODU, HP 6Ghz, ETSI TR240, 3B - Low Band
HP2-06-0252-1A ODU, HP2 6Ghz, ANSI/ETSI TR252, 1A - Low Band
HP2-06-0252-1B ODU, HP2 6Ghz, ANSI/ETSI TR252, 1B - Low Band
HP2-06-0252-2A ODU, HP2 6Ghz, ANSI/ETSI TR252, 2A - Low Band
HP2-06-0252-2B ODU, HP2 6Ghz, ANSI/ETSI TR252, 2B - Low Band
HP2-06-0252-3A ODU, HP2 6Ghz, ANSI/ETSI TR252, 3A - Low Band
HP2-06-0252-3B ODU, HP2 6Ghz, ANSI/ETSI TR252, 3B - Low Band
HP2-06-0252-4A ODU, HP2 6Ghz, ANSI/ETSI TR252, 4A - Low Band
HP2-06-0252-4B ODU, HP2 6Ghz, ANSI/ETSI TR252, 4B - Low Band
HP-06-0252-1A ODU, HP 6Ghz, ANSI/ETSI TR252, 1A - Low Band
HP-06-0252-1B ODU, HP 6Ghz, ANSI/ETSI TR252, 1B - Low Band
HP-06-0252-2A ODU, HP 6Ghz, ANSI/ETSI TR252, 2A - Low Band
HP-06-0252-2B ODU, HP 6Ghz, ANSI/ETSI TR252, 2B - Low Band
HP-06-0252-3A ODU, HP 6Ghz, ANSI/ETSI TR252, 3A - Low Band
HP-06-0252-3B ODU, HP 6Ghz, ANSI/ETSI TR252, 3B - Low Band
HP2-06-0300-1A ODU, HP2 6Ghz, ETSI TR300, 1A - Low Band
HP2-06-0300-1B ODU, HP2 6Ghz, ETSI TR300, 1B - Low Band
HP2-06-0300-2A ODU, HP2 6Ghz, ETSI TR300, 2A - Low Band
HP2-06-0300-2B ODU, HP2 6Ghz, ETSI TR300, 2B - Low Band
HP2-06-0300-3A ODU, HP2 6Ghz, ETSI TR300, 3A - Low Band
HP2-06-0300-3B ODU, HP2 6Ghz, ETSI TR300, 3B - Low Band
HP2-06-0300-4A ODU, HP2 6Ghz, ETSI TR300, 4A - Low Band
HP2-06-0300-4B ODU, HP2 6Ghz, ETSI TR300, 4B - Low Band
Trango Systems, Inc.
Description
GigaPlus User Manual Rev 3.1
TX Freq TX Freq Diplexer
Min* Max* Range
(MHz) (MHz) (MHz)
6,540 6,600 60
6,700 6,760 60
6,580 6,640 60
6,740 6,800 60
6,620 6,680 60
6,780 6,840 60
6,660 6,710 50
6,820 6,870 50
5,925 6,025 100
6,175 6,275 100
6,000 6,100 100
6,250 6,350 100
6,075 6,175 100
6,325 6,425 100
5,915.55 5,989.68 74
6,167.59 6,241.72 74
5,974.85 6,048.98 74
6,226.89 6,301.02 74
6,034.15 6,108.28 74
6,286.19 6,360.32 74
6,093.45 6,167.58 74
6,345.49 6,419.62 74
5,925 6,025 100
6,175 6,275 100
6,000 6,100 100
6,250 6,350 100
6,075 6,175 100
6,325 6,425 100
5,850 5,946 96
6,150 6,246 96
5,918 6,014 96
6,218 6,314 96
5,986 6,082 96
6,286 6,382 96
6,054 6,150 96
6,354 6,450 96
Max
Chan
Size
(MHz)
56
56
56
56
56
56
50
50
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
