Wireless Parameters

Parameter
Frequency Range
Channel Sizes Supported
Fixed Modulation Set Levels
Transmitter Power Accuracy
Transmitter Frequency Accuracy
Transmitter Center Frequency
Synthesizer step size
Transmitter Output Power (Muted )
Transmitter Output Return Loss
Adaptive Modulation Set Levels
Adaptive Modulation Type
Adaptive Modulation Transitions
Thresholds
Automatic Transmitter Power
Control

Transmitter Power

Modulation
6, 7, 8
QPSK
16QAM
32QAM
64QAM
128QAM
256QAM
Trango Systems, Inc.
6-40 GHz
3.5,5, 7,8.33, 10 , 12.5,13.75, 14, 20, 25, 27.5, 28, 30, 40, 50, 55,
56, 80 MHz
QAM256, QAM128, QAM64, QAM32, QAM16, QPSK
+/- 2 dB
+/- 7 ppm
250 kHz
< -50 dBm
> 10 dB
QAM256, QAM128, QAM64, QAM32, QAM16
Error Free, Hitless through each transition
User Settable MSE thresholds
> 15 dB range, user configurable step size and max power limit
Maximum Transmit Power by Frequency (dBm)
10
30 26.5
28 22.5
28 22.5
25 20.5
25 20.5
24 18.5
GigaPlus User Manual Rev 3.1
Specification
11 13,15
28 26
26 23
26 23
22 21
22 21
21 20
18-26 28-40
25 23
22 21
22 21
20 17
20 17
19 16
