power

SYNTAX
DESCRIPTION
Trango Systems, Inc.
power
power < 0-30 >
Default: 10 dBm
Configuration Storage: Yes
opmode without any parameter will display the current status of ODU
transmit power level
Power command is used to set the ODU transmit power level. The
maximum level is dependent upon the modulation and ODU model.
Ensure that the power does not exceed the rating for the modulation being
used or signal distortion will occur. SP ODU levels are shown here for
refrence.
SP ODU Model
18, 18E
6, 6E, 11, 11E
23, 23E
15E
GigaPlus User Manual Rev 3.1
Modulation
QAM256
QAM128
QAM64
QAM256
QAM128
QAM64
QAM32
QAM256
QAM16
QPSK
QPSK
QAM16
QAM64
Max Tx power
17
18
19
19
20
21
22
17
19
20
23
22
21
177
