The ACM feature will automatically shift the modulation level up or down based on the
!
MSE value and the above specified thresholds. If you do not want the radio to
automatically change speed settings then disable ACM.
Trango Systems, Inc.
Speed Setting QAM256
Modulation
QAM256
QAM64
QAM16
QPSK
Speed Setting using QAM128
Modulation
QAM128
QAM64
QAM32
QAM16
QPSK
Speed Setting using QAM64
Modulation
QAM64
QAM32
QAM16
QPSK
Speed Setting using QAM32
Modulation
QAM32
QAM16
QPSK
Speed Setting using QAM16
Modulation
QAM16
QPSK

Table 5 ACM Threshold Table

GigaPlus User Manual Rev 3.1
Improve Degrade
NA -27.2
-29.2 -24.3
-25.3 -18.5
-20.3 NA
Improve Degrade
NA -27.2
-29.2 -24.3
-26.3 -21.3
-25.3 -18.5
-20.3 NA
Improve Degrade
NA -24.3
-26.3 -21.3
-25.3 -18.5
-20.3 NA
Improve Degrade
NA -21.3
-25.3 -18.5
-20.3 NA
Improve Degrade
NA -18.5
-20.3 NA
