Trango Systems TrangoLINK GigaPlus User Manual page 231

Outdoor Unit
Part Numbers
HP ODUs, 7 GHZ
HP2-07-0150-1A ODU, HP2 7Ghz, ANSI TR150, 1A
HP2-07-0150-1B ODU, HP2 7Ghz, ANSI TR150, 1B
HP2-07-0150-2A ODU, HP2 7Ghz, ANSI TR150, 2A
HP2-07-0150-2B ODU, HP2 7Ghz, ANSI TR150, 2B
HP2-07-0154-1A ODU, HP2 7Ghz, ETSI TR154, 1A
HP2-07-0154-1B ODU, HP2 7Ghz, ETSI TR154, 1B
HP2-07-0154-2A ODU, HP2 7Ghz, ETSI TR154, 2A
HP2-07-0154-2B ODU, HP2 7Ghz, ETSI TR154, 2B
HP2-07-0154-3A ODU, HP2 7Ghz, ETSI TR154, 3A
HP2-07-0154-3B ODU, HP2 7Ghz, ETSI TR154, 3B
HP1-07-0154-1A ODU, HP 7Ghz, ETSI TR154, 1A
HP1-07-0154-1B ODU, HP 7Ghz, ETSI TR154, 1B
HP1-07-0154-2A ODU, HP 7Ghz, ETSI TR154, 2A
HP1-07-0154-2B ODU, HP 7Ghz, ETSI TR154, 2B
HP1-07-0154-3A ODU, HP 7Ghz, ETSI TR154, 3A
HP1-07-0154-3B ODU, HP 7Ghz, ETSI TR154, 3B
HP2-07-0160-1A ODU, HP2 7Ghz, ETSI TR160, 1A
HP2-07-0160-1B ODU, HP2 7Ghz, ETSI TR160, 1B
HP2-07-0160-2A ODU, HP2 7Ghz, ETSI TR160, 2A
HP2-07-0160-2B ODU, HP2 7Ghz, ETSI TR160, 2B
HP2-07-0160-3A ODU, HP2 7Ghz, ETSI TR160, 3A
HP2-07-0160-3B ODU, HP2 7Ghz, ETSI TR160, 3B
HP1-07-0160-1A ODU, HP 7Ghz, ETSI TR160, 1A
HP1-07-0160-1B ODU, HP 7Ghz, ETSI TR160, 1B
HP1-07-0160-2A ODU, HP 7Ghz, ETSI TR160, 2A
HP1-07-0160-2B ODU, HP 7Ghz, ETSI TR160, 2B
HP1-07-0160-3A ODU, HP 7Ghz, ETSI TR160, 3A
HP1-07-0160-3B ODU, HP 7Ghz, ETSI TR160, 3B
HP2-07-0161-1A ODU, HP2 7Ghz, ETSI TR161, 1A
HP2-07-0161-1B ODU, HP2 7Ghz, ETSI TR161, 1B
HP2-07-0161-2A ODU, HP2 7Ghz, ETSI TR161, 2A
HP2-07-0161-2B ODU, HP2 7Ghz, ETSI TR161, 2B
HP2-07-0161-3A ODU, HP2 7Ghz, ETSI TR161, 3A
HP2-07-0161-3B ODU, HP2 7Ghz, ETSI TR161, 3B
HP2-07-0161-4A ODU, HP2 7Ghz, ETSI TR161, 4A
HP2-07-0161-4B ODU, HP2 7Ghz, ETSI TR161, 4B
HP2-07-0161-5A ODU, HP2 7Ghz, ETSI TR161, 5A
HP2-07-0161-5B ODU, HP2 7Ghz, ETSI TR161, 5B
HP2-07-0161-6A ODU, HP2 7Ghz, ETSI TR161, 6A
HP2-07-0161-6B ODU, HP2 7Ghz, ETSI TR161, 6B
HP2-07-0161-7A ODU, HP2 7Ghz, ETSI TR161, 7A
HP2-07-0161-7B ODU, HP2 7Ghz, ETSI TR161, 7B
HP2-07-0161-8A ODU, HP2 7Ghz, ETSI TR161, 8A
HP2-07-0161-8B ODU, HP2 7Ghz, ETSI TR161, 8B
HP2-07-0161-9A ODU, HP2 7Ghz, ETSI TR161, 9A
HP2-07-0161-9B ODU, HP2 7Ghz, ETSI TR161, 9B
HP2-07-0161-10A ODU, HP2 7Ghz, ETSI TR161, 10A
HP2-07-0161-10B ODU, HP2 7Ghz, ETSI TR161, 10B
HP2-07-0161-21A ODU, HP2 7Ghz, ETSI TR161, 21A
HP2-07-0161-21B ODU, HP2 7Ghz, ETSI TR161, 21B
HP2-07-0161-22A ODU, HP2 7Ghz, ETSI TR161, 22A
HP2-07-0161-22B ODU, HP2 7Ghz, ETSI TR161, 22B
HP2-07-0161-23A ODU, HP2 7Ghz, ETSI TR161, 23A
HP2-07-0161-23B ODU, HP2 7Ghz, ETSI TR161, 23B
HP2-07-0161-24A ODU, HP2 7Ghz, ETSI TR161, 24A
HP2-07-0161-24B ODU, HP2 7Ghz, ETSI TR161, 24B
HP2-07-0161-25A ODU, HP2 7Ghz, ETSI TR161, 25A
HP2-07-0161-25B ODU, HP2 7Ghz, ETSI TR161, 25B
HP2-07-0161-26A ODU, HP2 7Ghz, ETSI TR161, 26A
HP2-07-0161-26B ODU, HP2 7Ghz, ETSI TR161, 26B
Trango Systems, Inc.
Description
GigaPlus User Manual Rev 3.1
TX Freq TX Freq Diplexer
Min* Max* Range
(MHz) (MHz) (MHz)
6,875 6,945 70
7,025 7,095 70
6,905 6,975 70
7,055 7,125 70
7,428 7,484 56
7,582 7,638 56
7,470 7,526 56
7,624 7,680 56
7,512 7,568 56
7,666 7,722 56
7,428 7,484 56
7,582 7,638 56
7,470 7,526 56
7,624 7,680 56
7,512 7,568 56
7,666 7,722 56
7,434 7,497 63
7,594 7,657 63
7,479 7,542 63
7,639 7,702 63
7,526 7,589 63
7,686 7,749 63
7,433.5 7,496.5 63
7,593.5 7,656.5 63
7,478.5 7,541.5 63
7,638.5 7,701.5 63
7,526.0 7,589.0 63
7,686.0 7,749.0 63
7,114 7,177 63
7,275 7,338 63
7,149 7,212 63
7,310 7,373 63
7,184 7,247 63
7,345 7,408 63
7,219 7,282 63
7,380 7,443 63
7,239 7,302 63
7,400 7,463 63
7,274 7,337 63
7,435 7,498 63
7,309 7,372 63
7,470 7,533 63
7,344 7,407 63
7,505 7,568 63
7,414 7,477 63
7,575 7,638 63
7,449 7,512 63
7,610 7,673 63
7,484 7,547 63
7,645 7,708 63
7,519 7,582 63
7,680 7,743 63
7,539 7,602 63
7,700 7,763 63
7,574 7,637 63
7,735 7,798 63
7,609 7,672 63
7,770 7,833 63
7,644 7,707 63
7,805 7,868 63
Max
Chan
Size
(MHz)
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
231
