Accessories

Model Antenna
HP ODUs - 6 GHZ
HP-06-0240-xx AD6GL-xx-R2, -R3
HP-06-0252-xx AD6GL-xx-R2, -R3
HP-06-0340-xx AD6GU-xx-R2, -R3 SMC-06-3-HP
HP2-06-0160-xx AD6GU-xx-R4, -R3 SMC-06-3-HP2 SMC-06-6-HP2 OMC-06-HP2 HP2-MNT-6-WR137 SMC-06-3-HP-R
HP2-06-0170-xx AD6GU-xx-R4, -R3 SMC-06-3-HP2 SMC-06-6-HP2 OMC-06-HP2 HP2-MNT-6-WR137 SMC-06-3-HP-R
HP2-06-0252-xx AD6GL-xx-R4, -R3
HP2-06-0300-xx AD6GL-xx-R4, -R3
HP2-06-0340-xx AD6GU-xx-R4, -R3 SMC-06-3-HP2 SMC-06-6-HP2 OMC-06-HP2 HP2-MNT-6-WR137 SMC-06-3-HP-R
HP2-06-0350-xx AD6GU-xx-R4, -R3 SMC-06-3-HP2 SMC-06-6-HP2 OMC-06-HP2 HP2-MNT-6-WR137 SMC-06-3-HP-R
Note: All -R3 Antennas require a Remote Mount for the ODU and Waveguide
HP ODUs - 7 GHZ
HP-07-xxxx-xx AD7G-xx-S2
HP2-07-xxxx-xx AD7G-xx-S2
HP ODUs - 8 GHZ
HP-08-xxxx-xx AD8G-xx-R2
HP2-08-xxxx-xx AD8G-xx-R2
HP ODUs - 10 GHZ
HP2-10-xxxx-xx AD10G-xx-S2
HP ODUs - 11 GHZ
HP-11-xxxx-xx AD11G-xx-S2, -R2
HP2-11-xxxx-xx AD11G-xx-S2, -R2
HP ODUs - 13 GHZ
HP-13-xxxx-xx AD13G-xx-S2, -R2
HP2-13-xxxx-xx AD13G-xx-S2, -R2
HP ODUs - 15GHZ
HP-15-xxxx-xx AD15G-xx-S2
HP2-15-xxxx-xx AD15G-xx-S2
HP ODUs - 18 GHZ
HP-18-xxxx-xx AD18G-xx-S2, R2
HP2-18-xxxx-xx AD18G-xx-S2, R2
HP ODUs - 23 GHZ
HP-23-xxxx-xx AD23G-xx-S2, -R2
HP2-23-xxxx-xx AD23G-xx-S2, -R2
HP ODUs - 26 GHZ
HP-26-xxxx-xx AD26G-xx-S2
HP2-26-xxxx-xx AD26G-xx-S2
HP ODUs - 26 GHZ
HP-28-xxxx-xx AD28G-xx-R2
HP ODUs - 32 GHZ
HP-32-xxxx-xx AD32G-xx-R2
HP ODUs - 38 GHZ
HP-38-xxxx-xx AD38G-xx-R2
HP-38-xxxx-xx AD38G-xx-R2
HP2-38-xxxx-xx AD38G-xx-R2
Trango Systems, Inc.
TRANGO PtP MICROWAVE BAND SPECIFIC ACCESSORIES
3/3 dB Dir 1.9/6 dB Dir
Mnt Comb Mnt Comb
SMC-06-3-HP SMC-06-6-HP
SMC-06-3-HP SMC-06-6-HP
SMC-06-6-HP
SMC-06-3-HP2 SMC-06-6-HP2 OMC-06-HP2 HP2-MNT-6-WR137 SMC-06-3-HP-R
SMC-06-3-HP2 SMC-06-6-HP2 OMC-06-HP2 HP2-MNT-6-WR137 SMC-06-3-HP-R
SMC-78-3-HP SMC-78-6-HP
SMC-78-3-HP SMC-78-6-HP
SMC-78-3-HP SMC-78-6-HP
SMC-78-3-HP SMC-78-6-HP
NA NA
SMC-11-3-HP SMC-11-6-HP
SMC-11-3-HP SMC-11-6-HP
SMC-13-3-HP SMC-13-6-HP
SMC-13-3-HP SMC-13-6-HP
SMC-15-3-HP SMC-15-6-HP
SMC-15-3-HP SMC-15-6-HP
SMC-18-3-HP SMC-18-6-HP
SMC-18-3-HP SMC-18-6-HP
SMC-23-3-HP SMC-23-6-HP
SMC-23-3-HP SMC-23-6-HP
SMC-26-3-HP SMC-26-6-HP
SMC-26-3-HP SMC-26-6-HP
SMC-28-3-HP SMC-28-6-HP
SMC-32-3-HP SMC-32-6-HP
SMC-38-3-HP SMC-38-6-HP
SMC-38-3-HP SMC-38-6-HP
SMC-38-3-HP SMC-38-6-HP
GigaPlus User Manual Rev 3.1
Dir Mnt
Ortho
Comb Remote Mount
OMC-06-HP HP-MNT-06-WR137 SMC-06-3-HP-R
OMC-06-HP HP-MNT-06-WR137 SMC-06-3-HP-R
OMC-06-HP HP-MNT-06-WR137 SMC-06-3-HP-R
OMC-07-HP HP-MNT-78-WR112 SMC-78-3-HP-R
OMC-07-HP HP-MNT-78-WR112 SMC-78-3-HP-R
OMC-07-HP HP-MNT-78-WR112 SMC-78-3-HP-R
OMC-07-HP HP-MNT-78-WR112 SMC-78-3-HP-R
NA NA
OMC-11-HP HP-MNT-11-WR75
OMC-11-HP HP-MNT-11-WR75
OMC-13-HP HP-MNT-13-WR75
OMC-13-HP HP-MNT-13-WR75
OMC-15-HP HP-MNT-15-WR62
OMC-15-HP HP-MNT-15-WR62
OMC-18-HP HP-MNT-18-WR42
OMC-18-HP HP-MNT-18-WR42
OMC-23-HP HP-MNT-23-WR42
OMC-23-HP HP-MNT-23-WR42
NA HP-MNT-26-WR42
NA HP-MNT-26-WR42
NA HP-MNT-28-WR28
NA HP-MNT-32-WR28
OMC-38-HP HP-MNT-38-WR28
OMC-38-HP HP-MNT-38-WR28
OMC-38-HP HP-MNT-38-WR28
Rem Mnt 3/3 Rem Mnt 1.9/6
dB Comb dB Comb
SMC-06-6-HP-R
SMC-06-6-HP-R
SMC-06-6-HP-R
SMC-06-6-HP-R
SMC-06-6-HP-R
SMC-06-6-HP-R
SMC-06-6-HP-R
SMC-06-6-HP-R
SMC-06-6-HP-R
SMC-78-6-HP-R
SMC-78-6-HP-R
SMC-78-6-HP-R
SMC-78-6-HP-R
NA NA
SMC-11-3-HP-R SMC-11-6-HP-R
SMC-11-3-HP-R SMC-11-6-HP-R
SMC-13-3-HP-R SMC-13-6-HP-R
SMC-13-3-HP-R SMC-13-6-HP-R
SMC-15-3-HP-R SMC-15-6-HP-R
SMC-15-3-HP-R SMC-15-6-HP-R
SMC-18-3-HP-R SMC-18-6-HP-R
SMC-18-3-HP-R SMC-18-6-HP-R
SMC-23-6-HP-R SMC-26-3-HP-R
SMC-23-6-HP-R SMC-26-3-HP-R
SMC-26-3-HP-R SMC-26-6-HP-R
SMC-26-3-HP-R SMC-26-6-HP-R
SMC-28-3-HP-R SMC-28-6-HP-R
SMC-32-3-HP-R SMC-32-6-HP-R
SMC-38-3-HP-R SMC-38-6-HP-R
SMC-38-3-HP-R SMC-38-6-HP-R
SMC-38-3-HP-R SMC-38-6-HP-R
