EXAMPLE
Trango Systems, Inc.
Norm-MSE > Radial MSE there is some amplitude noise (AM
distortion)
Norm-MSE < Radial MSE phase noise residue exist, that the PLL did
not fully correct
Uncorrect Block: Error reported by modem when passing traffics.
Power sensors: used to make sure TX power accuracy. Some models
uses only IF while other using only the RF values.
Odu attn: Make sure the attenuators are been set correctly.
Note: Block counter & uncorrect block counter are accumulative
values since the last link establishment. They are collected on a 20
second periodic basis.
(CLI-view)# siglevel
IDU RSSI:
Normalized MSE:
Radial MSE:
LDPC Decoder Stress:
External AGC:
Carrier Offset:
Rx Symrate:
Block Counter:
Uncorrect Block:
LDPC Avg Iteration:
Output corrected bytes:
Return Loss:
Tx Power alarm:
Tx PA alarm:
PA on/off alarm:
Tx Power Range alarm:
Tx Power actual:
Rx Power actual:
Channel test:
Telemetry debug:
(CLI-view)#
GigaPlus User Manual Rev 3.1
0
-348
-340
0
1604
2466
49500732
0
0
0
0
0x0000
ok
ok
on
ok
20.00
-23.00
Pass
Fail
