Trango Systems TrangoLINK GigaPlus User Manual page 237

Outdoor Unit
Part Numbers
HP2-15-0490-4A ODU, HP2 15Ghz, ETSI TR490, 4A
HP2-15-0490-4B ODU, HP2 15Ghz, ETSI TR490, 4B
HP2-15-0490-5A ODU, HP2 15Ghz, ETSI TR490, 5A
HP2-15-0490-5B ODU, HP2 15Ghz, ETSI TR490, 5B
HP2-15-0490-6A ODU, HP2 15Ghz, ETSI TR490, 6A
HP2-15-0490-6B ODU, HP2 15Ghz, ETSI TR490, 6B
HP2-15-0490-7A ODU, HP2 15Ghz, ETSI TR490, 7A
HP2-15-0490-7B ODU, HP2 15Ghz, ETSI TR490, 7B
HP1-15-0490-4A ODU, HP 15Ghz, ETSI TR490, 4A
HP1-15-0490-4B ODU, HP 15Ghz, ETSI TR490, 4B
HP1-15-0490-5A ODU, HP 15Ghz, ETSI TR490, 5A
HP1-15-0490-5B ODU, HP 15Ghz, ETSI TR490, 5B
HP1-15-0490-6A ODU, HP 15Ghz, ETSI TR490, 6A
HP1-15-0490-6B ODU, HP 15Ghz, ETSI TR490, 6B
HP1-15-0490-7A ODU, HP 15Ghz, ETSI TR490, 7A
HP1-15-0490-7B ODU, HP 15Ghz, ETSI TR490, 7B
HP2-15-0475-1A ODU, HP2 15Ghz, ETSI TR475, 1A
HP2-15-0475-1B ODU, HP2 15Ghz, ETSI TR475, 1B
HP2-15-0475-2A ODU, HP2 15Ghz, ETSI TR475, 2A
HP2-15-0475-2B ODU, HP2 15Ghz, ETSI TR475, 2B
HP2-15-0475-3A ODU, HP2 15Ghz, ETSI TR475, 3A
HP2-15-0475-3B ODU, HP2 15Ghz, ETSI TR475, 3B
HP1-15-0475-1A ODU, HP 15Ghz, ETSI TR475, 1A
HP1-15-0475-1B ODU, HP 15Ghz, ETSI TR475, 1B
HP1-15-0475-2A ODU, HP 15Ghz, ETSI TR475, 2A
HP1-15-0475-2B ODU, HP 15Ghz, ETSI TR475, 2B
HP1-15-0475-3A ODU, HP 15Ghz, ETSI TR475, 3A
HP1-15-0475-3B ODU, HP 15Ghz, ETSI TR475, 3B
HP2-15-0640-1A ODU, HP2 15Ghz, ETSI TR640, 1A
HP2-15-0640-1B ODU, HP2 15Ghz, ETSI TR640, 1B
HP2-15-0640-2A ODU, HP2 15Ghz, ETSI TR640, 2A
HP2-15-0640-2B ODU, HP2 15Ghz, ETSI TR640, 2B
HP1-15-0640-1A ODU, HP 15Ghz, ETSI TR640, 1A
HP1-15-0640-1B ODU, HP 15Ghz, ETSI TR640, 1B
HP1-15-0640-2A ODU, HP 15Ghz, ETSI TR640, 2A
HP1-15-0640-2B ODU, HP 15Ghz, ETSI TR640, 2B
HP2-15-0644-1A ODU, HP2 15Ghz, ETSI TR644, 1A
HP2-15-0644-1B ODU, HP2 15Ghz, ETSI TR644, 1B
HP2-15-0644-2A ODU, HP2 15Ghz, ETSI TR644, 2A
HP2-15-0644-2B ODU, HP2 15Ghz, ETSI TR644, 2B
HP2-15-0644-3A ODU, HP2 15Ghz, ETSI TR644, 3A
HP2-15-0644-3B ODU, HP2 15Ghz, ETSI TR644, 3B
HP1-15-0644-1A ODU, HP 15Ghz, ETSI TR644, 1A
HP1-15-0644-1B ODU, HP 15Ghz, ETSI TR644, 1B
HP1-15-0644-2A ODU, HP 15Ghz, ETSI TR644, 2A
HP1-15-0644-2B ODU, HP 15Ghz, ETSI TR644, 2B
HP1-15-0644-3A ODU, HP 15Ghz, ETSI TR644, 3A
HP1-15-0644-3B ODU, HP 15Ghz, ETSI TR644, 3B
Trango Systems, Inc.
Description
GigaPlus User Manual Rev 3.1
TX Freq TX Freq Diplexer
Min* Max* Range
(MHz) (MHz) (MHz)
14,403 14,522 119
14,893 15,012 119
14,515 14,634 119
15,005 15,124 119
14,627 14,746 119
15,117 15,236 119
14,739 14,858 119
15,229 15,348 119
14,403 14,522 119
14,893 15,012 119
14,515 14,634 119
15,005 15,124 119
14,627 14,746 119
15,117 15,236 119
14,739 14,858 119
15,229 15,348 119
14,500 14,668 168
14,975 15,143 168
14,660 14,828 168
15,135 15,303 168
14,715 14,883 168
15,190 15,358 168
14,500 14,668 168
14,975 15,143 168
14,660 14,828 168
15,135 15,303 168
14,783 14,883 100
15,258 15,358 100
14,500 14,610 110
15,140 15,250 110
14,605 14,715 110
15,245 15,355 110
14,500 14,610 110
15,140 15,250 110
14,605 14,715 110
15,245 15,355 110
14,400 14,512 112
15,044 15,156 112
14,498 14,610 112
15,142 15,254 112
14,596 14,708 112
15,240 15,352 112
14,400 14,512 112
15,044 15,156 112
14,498 14,610 112
15,142 15,254 112
14,596 14,708 112
15,240 15,352 112
Max
Chan
Size
(MHz)
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
237
