Trango Systems TrangoLINK GigaPlus User Manual page 235

Outdoor Unit
Part Numbers
HP2-08-0266-1A ODU, HP2 8Ghz, ETSI TR266, 1A
HP2-08-0266-1B ODU, HP2 8Ghz, ETSI TR266, 1B
HP2-08-0266-2A ODU, HP2 8Ghz, ETSI TR266, 2A
HP2-08-0266-2B ODU, HP2 8Ghz, ETSI TR266, 2B
HP1-08-0266-1A ODU, HP 8Ghz, ETSI TR266, 1A
HP1-08-0266-1B ODU, HP 8Ghz, ETSI TR266, 1B
HP1-08-0266-2A ODU, HP 8Ghz, ETSI TR266, 2A
HP1-08-0266-2B ODU, HP 8Ghz, ETSI TR266, 2B
HP2-08-0311-1A ODU, HP2 8Ghz, ETSI TR311, 1A
HP2-08-0311-1B ODU, HP2 8Ghz, ETSI TR311, 1B
HP2-08-0311-2A ODU, HP2 8Ghz, ETSI TR311, 2A
HP2-08-0311-2B ODU, HP2 8Ghz, ETSI TR311, 2B
HP1-08-0311-2A ODU, HP 8Ghz, ETSI TR311, 2A
HP1-08-0311-2B ODU, HP 8Ghz, ETSI TR311, 2B
HP1-08-0311-3A ODU, HP 8Ghz, ETSI TR311, 3A
HP1-08-0311-3B ODU, HP 8Ghz, ETSI TR311, 3B
HP ODUs,- 10 GHZ
HP2-10-0350-1A ODU, HP2 10Ghz, ETSI TR350, 1A
HP2-10-0350-1B ODU, HP2 10Ghz, ETSI TR350, 1B
HP ODUs,- 10.5 GHZ
HP2-10-091-1A ODU, HP2 10.5Ghz, ANSI TR91, 1A
HP2-10-091-1B ODU, HP2 10.5Ghz, ANSI TR91, 1B
HP2-10-091-2A ODU, HP2 10.5Ghz, ANSI TR91, 2A
HP2-10-091-2B ODU, HP2 10.5Ghz, ANSI TR91, 2B
HP2-10-091-3A ODU, HP2 10.5Ghz, ANSI TR91, 3A
HP2-10-091-3B ODU, HP2 10.5Ghz, ANSI TR91, 3B
HP ODUs, – 11 GHZ
HP2-11-0490-5A ODU, HP2 11Ghz, ANSI/ETSI TR490/500, 5A
HP2-11-0490-5B ODU, HP2 11Ghz, ANSI/ETSI TR490/500, 5B
HP2-11-0490-6A ODU, HP2 11Ghz, ANSI/ETSI TR490/500, 6A
HP2-11-0490-6B ODU, HP2 11Ghz, ANSI/ETSI TR490/500, 6B
HP2-11-0490-7A ODU, HP2 11Ghz, ANSI/ETSI TR490/500, 7A
HP2-11-0490-7B ODU, HP2 11Ghz, ANSI/ETSI TR490/500, 7B
HP1-11-0490-5A ODU, HP 11Ghz, ANSI/ETSI TR490/500, 5A
HP1-11-0490-5B ODU, HP 11Ghz, ANSI/ETSI TR490/500, 5B
HP1-11-0490-6A ODU, HP 11Ghz, ANSI/ETSI TR490/500, 6A
HP1-11-0490-6B ODU, HP 11Ghz, ANSI/ETSI TR490/500, 6B
HP1-11-0490-7A ODU, HP 11Ghz, ANSI/ETSI TR490/500, 7A
HP1-11-0490-7B ODU, HP 11Ghz, ANSI/ETSI TR490/500, 7B
HP2-11-0530-1A ODU, HP2 11Ghz, ETSI TR530, 1A
HP2-11-0530-1B ODU, HP2 11Ghz, ETSI TR530, 1B
HP2-11-0530-2A ODU, HP2 11Ghz, ETSI TR530, 2A
HP2-11-0530-2B ODU, HP2 11Ghz, ETSI TR530, 2B
HP2-11-0530-3A ODU, HP2 11Ghz, ETSI TR530, 3A
HP2-11-0530-3B ODU, HP2 11Ghz, ETSI TR530, 3B
HP2-11-0530-4A ODU, HP2 11Ghz, ETSI TR530, 4A
HP2-11-0530-4B ODU, HP2 11Ghz, ETSI TR530, 4B
HP1-11-0530-1A ODU, HP 11Ghz, ETSI TR530, 1A
HP1-11-0530-1B ODU, HP 11Ghz, ETSI TR530, 1B
HP1-11-0530-2A ODU, HP 11Ghz, ETSI TR530, 2A
HP1-11-0530-2B ODU, HP 11Ghz, ETSI TR530, 2B
HP1-11-0530-3A ODU, HP 11Ghz, ETSI TR530, 3A
HP1-11-0530-3B ODU, HP 11Ghz, ETSI TR530, 3B
HP1-11-0530-4A ODU, HP 11Ghz, ETSI TR530, 4A
HP1-11-0530-4B ODU, HP 11Ghz, ETSI TR530, 4B
Trango Systems, Inc.
Description
GigaPlus User Manual Rev 3.1
TX Freq TX Freq Diplexer
Min* Max* Range
(MHz) (MHz) (MHz)
7,905 8,024 119
8,171 8,290 119
8,017 8,136 119
8,283 8,402 119
7,905 8,024 119
8,171 8,290 119
8,017 8,136 119
8,283 8,402 119
7,731 7,867 136
8,042 8,178 136
7,835 7,971 136
8,146 8,282 136
7,835 7,971 136
8,146 8,282 136
7,717 7,867 150
8,028 8,178 150
10,150 10,300 150
10,500 10,650 150
10,500 10,531 30
10,591 10,622 30
10,528 10,559 30
10,619 10,650 30
10,556 10,587 30
10,647 10,678 30
10,700 10,890 190
11,200 11,390 190
10,855 11,045 190
11,355 11,545 190
11,010 11,200 190
11,510 11,700 190
10,700 10,890 190
11,200 11,390 190
10,855 11,045 190
11,355 11,545 190
11,010 11,200 190
11,510 11,700 190
10,675 10,855 180
11,205 11,385 180
10,795 10,975 180
11,325 11,505 180
10,915 11,135 220
11,445 11,665 220
11,035 11,215 180
11,565 11,745 180
10,675 10,855 180
11,205 11,385 180
10,795 10,975 180
11,325 11,505 180
10,915 11,135 220
11,445 11,665 220
11,035 11,215 180
11,565 11,745 180
Max
Chan
Size
(MHz)
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
30
30
30
30
30
30
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
56
