Speed - Trango Systems TrangoLINK GigaPlus User Manual

speed

SYNTAX
DESCRIPTION
Speed Setting Modulation
(Actual BW)
Trango Systems, Inc.
speed <bandwidth> <modulation>
<bandwidth>: 4,5,7,8,10,12,14,20,25,28,30,40,50,56,80
<modulation>: qpsk, qam16, qam32, qam64, qam128, qam256
Default: bandwidth 30, QAM32
Configuration Storage: Yes
speed without any parameter will display the current speed setting
Load the corresponding the modem binary and configure Tx and Rx
bandpass filters.
The speed command will also configure the modem protection mode
based on the system_mode configuration. Only when the 1+1 HSB mode is
set, the modem may be configured as working or protection mode.
Binaries selection for the speed command is based on 5 different
configuration: tdm_mode, acm enable, modulation and bandwidth.
Making changes via the tdm_mode, or acm enable commands will
require a subsequent re-load of the speed setting for proper operation.
IF RX
LPF (MHz)
GigaPlus User Manual Rev 3.1
IF TX Total
LPF (MHz) Capacity
Symbol License key
Rate
187
