Ipconfig - Trango Systems TrangoLINK GigaPlus User Manual

DESCRIPTION

ipconfig

SYNTAX
Trango Systems, Inc.
ibm vlanid <1-4088>
Default: enable=OFF, ip=172.16.10.0, netmask=255.255.0.0, vlanid=100.
Configuration Storage: Yes
Ibm without any parameter will display the current IBM features
parameters.
Ibm is used to configure the In Band Management (IBM) channel to
manage the system.
Both IBM and the Out of Band Management (OBM) can be used together.
The management VLAN ID can be configured based on the user
requirement from 1-4090. The IP address for the IBM channel is
independent of the OBM port on the IDU. The 2 IP addresses need to be
unique.
ipconfig
ipconfig ip [ip_addr] [netmask]
ipconfig gateway [default_gateway_ip]
Default: IP=192.168.100.100, NETMASK=255.255.255.0,
GATEWAY=192.168.100.100
Configuration Storage: Yes
ipconfig without any parameter will display the current IP configuration
GigaPlus User Manual Rev 3.1
166
